6UX9

Crystal Structure Analysis of PIP4K2A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.71 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.177
  • R-Value Observed: 0.178

wwPDB Validation   3D Report Full Report

Currently 6UX9 does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Discovery and Structure-Activity Relationship Study of ( Z )-5-Methylenethiazolidin-4-one Derivatives as Potent and Selective Pan-phosphatidylinositol 5-Phosphate 4-Kinase Inhibitors.

Manz, T.D.Sivakumaren, S.C.Ferguson, F.M.Zhang, T.Yasgar, A.Seo, H.S.Ficarro, S.B.Card, J.D.Shim, H.Miduturu, C.V.Simeonov, A.Shen, M.Marto, J.A.Dhe-Paganon, S.Hall, M.D.Cantley, L.C.Gray, N.S.

(2020) J Med Chem 63: 4880-4895

  • DOI: https://doi.org/10.1021/acs.jmedchem.0c00227
  • Primary Citation of Related Structures:
    6UX9

  • PubMed Abstract:

    Due to their role in many important signaling pathways, phosphatidylinositol 5-phosphate 4-kinases (PI5P4Ks) are attractive targets for the development of experimental therapeutics for cancer, metabolic, and immunological disorders. Recent efforts to develop small molecule inhibitors for these lipid kinases resulted in compounds with low- to sub-micromolar potencies. Here, we report the identification of CVM-05-002 using a high-throughput screen of PI5P4Kα against our in-house kinase inhibitor library. CVM-05-002 is a potent and selective inhibitor of PI5P4Ks, and a 1.7 Å X-ray structure reveals its binding interactions in the ATP-binding pocket. Further investigation of the structure-activity relationship led to the development of compound 13 , replacing the rhodanine-like moiety present in CVM-05-002 with an indole, a potent pan-PI5P4K inhibitor with excellent kinome-wide selectivity. Finally, we employed isothermal cellular thermal shift assays (CETSAs) to demonstrate the effective cellular target engagement of PI5P4Kα and -β by the inhibitors in HEK 293T cells.


  • Organizational Affiliation

    Department of Cancer Biology, Dana-Farber Cancer Institute, 360 Longwood Avenue, Boston, Massachusetts 02215, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Phosphatidylinositol 5-phosphate 4-kinase type-2 alpha
A, B
370Homo sapiensMutation(s): 0
Gene Names: PIP4K2APIP5K2PIP5K2A
EC: 2.7.1.149
UniProt & NIH Common Fund Data Resources
Find proteins for P48426 (Homo sapiens)
Explore P48426
Go to UniProtKB:  P48426
PHAROS:  P48426
GTEx:  ENSG00000150867
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP48426
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
UHJ (Subject of Investigation/LOI)
Query on UHJ

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
N-[4-(5-{(Z)-[(2E)-2-imino-4-oxo-1,3-thiazolidin-5-ylidene]methyl}pyridin-3-yl)phenyl]methanesulfonamide
C16 H14 N4 O3 S2
AGHDPPGOJJYURV-AUWJEWJLSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.71 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.177
  • R-Value Observed: 0.178
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.23α = 90
b = 88.58β = 92.91
c = 105.78γ = 90
Software Package:
Software NamePurpose
XSCALEdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
xia2data reduction
PHENIXphasing

Structure Validation

View Full Validation Report

Currently 6UX9 does not have a validation slider image.



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2020-12-09
    Type: Initial release
  • Version 1.1: 2021-12-22
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Refinement description
