6UUY

Schistosoma haematobium (Blood Fluke) Sulfotransferase/Hycanthone Complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.37 Å
  • R-Value Free: 0.176
  • R-Value Work: 0.148
  • R-Value Observed: 0.148

wwPDB Validation   3D Report Full Report

Currently 6UUY does not have a validation slider image.


This is version 1.2 of the entry. See complete history


Literature

Molecular basis for hycanthone drug action in schistosome parasites.

Guzman, M.Rugel, A.Tarpley, R.S.Cao, X.McHardy, S.F.LoVerde, P.T.Taylor, A.B.

(2020) Mol Biochem Parasitol 236: 111257-111257

  • DOI: https://doi.org/10.1016/j.molbiopara.2020.111257
  • Primary Citation of Related Structures:
    6UUX, 6UUY

  • PubMed Abstract:

    Hycanthone (HYC) is a retired drug formerly used to treat schistosomiasis caused by infection from Schistosoma mansoni and S. haematobium. Resistance to HYC was first observed in S. mansoni laboratory strains and in patients in the 1970s and the use of this drug was subsequently discontinued with the substitution of praziquantel (PZQ) as the single antischistosomal drug in the worldwide formulary. In endemic regions, multiple organizations have partnered with the World Health Organization to deliver PZQ for morbidity control and prevention. While the monotherapy reduces the disease burden, additional drugs are needed to use in combination with PZQ to stay ahead of potential drug resistance. HYC will not be reintroduced into the schistosomiasis drug formulary as a combination drug because it was shown to have adverse properties including mutagenic, teratogenic and carcinogenic activities. Oxamniquine (OXA) was used to treat S. mansoni infection in Brazil during the brief period of HYC use, until the 1990s. Its antischistosomal efficacy has been shown to work through the same mechanism as HYC and it does not possess the undesirable properties linked to HYC. OXA demonstrates cross-resistance in Schistosoma strains with HYC resistance and both are prodrugs requiring metabolic activation in the worm to toxic sulfated forms. The target activating enzyme has been identified as a sulfotransferase enzyme and is currently used as the basis for a structure-guided drug design program. Here, we characterize the sulfotransferases from S. mansoni and S. haematobium in complexes with HYC to compare and contrast with OXA-bound sulfotransferase crystal structures. Although HYC is discontinued for antischistosomal treatment, it can serve as a resource for design of derivative compounds without contraindication.


  • Organizational Affiliation

    Department of Pathology and Laboratory Medicine, University of Texas Health Science Center at San Antonio, San Antonio, TX 78229, United States; Department of Microbiology, Immunology & Molecular Genetics, University of Texas Health Science Center at San Antonio, San Antonio, TX 78229, United States; Department of Biochemistry & Structural Biology, University of Texas Health Science Center at San Antonio, San Antonio, TX 78229, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Sulfotransferase
A, B
253Schistosoma haematobiumMutation(s): 0
Gene Names: MS3_07706
EC: 2.8.2
UniProt
Find proteins for A0A094ZWQ2 (Schistosoma haematobium)
Explore A0A094ZWQ2
Go to UniProtKB:  A0A094ZWQ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A094ZWQ2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A3P
Query on A3P

Download Ideal Coordinates CCD File
C [auth A],
E [auth B]
ADENOSINE-3'-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
WHTCPDAXWFLDIH-KQYNXXCUSA-N
QHM (Subject of Investigation/LOI)
Query on QHM

Download Ideal Coordinates CCD File
D [auth A],
F [auth B]
hycanthone
C20 H24 N2 O2 S
MFZWMTSUNYWVBU-UHFFFAOYSA-N
BCN
Query on BCN

Download Ideal Coordinates CCD File
I [auth B]BICINE
C6 H13 N O4
FSVCELGFZIQNCK-UHFFFAOYSA-N
MPD
Query on MPD

Download Ideal Coordinates CCD File
G [auth B](4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
CA
Query on CA

Download Ideal Coordinates CCD File
H [auth B],
J [auth B]
CALCIUM ION
Ca
BHPQYMZQTOCNFJ-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
QHM Binding MOAD:  6UUY Kd: 2500 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.37 Å
  • R-Value Free: 0.176
  • R-Value Work: 0.148
  • R-Value Observed: 0.148
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 51.69α = 90
b = 73.21β = 90
c = 138.79γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report

Currently 6UUY does not have a validation slider image.



Entry History & Funding Information

Deposition Data

  • Released Date: 2020-02-19
  • Deposition Author(s): Taylor, A.B.

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI115691

Revision History  (Full details and data files)

  • Version 1.0: 2020-02-19
    Type: Initial release
  • Version 1.1: 2020-02-26
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Derived calculations, Refinement description
