Biological Assembly 1

 3D View: Structure | 1D-3D View | Electron Density | Validation Report

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 3-mer - A3

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: microscopy

Macromolecule Content

• Total Structure Weight: 137.76 kDa
• Atom Count: 2439
• Modelled Residue Count: 321
• Deposited Residue Count: 1323
• Unique protein chains: 1

6TJO

Cryo-EM structure of TypeI tau filaments extracted from the brains of individuals with Corticobasal degeneration

• PDB DOI: 10.2210/pdb6TJO/pdb
• EM Map EMD-10512: EMDB EMDataResource

• Classification: PROTEIN FIBRIL
• Organism(s): Homo sapiens
• Mutation(s): No


• Deposited: 2019-11-26 Released: 2020-02-05
• Deposition Author(s): Zhang, W., Murzin, A.G., Falcon, B., Shi, Y., Goedert, M., Scheres, S.H.W.
• Funding Organization(s): Medical Research Council (United Kingdom)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.20 Å
• Aggregation State: FILAMENT
• Reconstruction Method: HELICAL

Literature

Novel tau filament fold in corticobasal degeneration.

Zhang, W., Tarutani, A., Newell, K.L., Murzin, A.G., Matsubara, T., Falcon, B., Vidal, R., Garringer, H.J., Shi, Y., Ikeuchi, T., Murayama, S., Ghetti, B., Hasegawa, M., Goedert, M., Scheres, S.H.W.

(2020) Nature 580: 283-287

• PubMed: 32050258
• DOI: 10.1038/s41586-020-2043-0
• Primary Citation of Related Structures:
  6TJO, 6TJX


• PubMed Abstract:


Corticobasal degeneration (CBD) is a neurodegenerative tauopathy-a class of disorders in which the tau protein forms insoluble inclusions in the brain-that is characterized by motor and cognitive disturbances ^1-3 . The H1 haplotype of MAPT (the tau gene) is present in cases of CBD at a higher frequency than in controls ^4,5 , and genome-wide association studies have identified additional risk factors ⁶ . By histology, astrocytic plaques are diagnostic of CBD ^7,8 ; by SDS-PAGE, so too are detergent-insoluble, 37 kDa fragments of tau ⁹ . Like progressive supranuclear palsy, globular glial tauopathy and argyrophilic grain disease ¹⁰ , CBD is characterized by abundant filamentous tau inclusions that are made of isoforms with four microtubule-binding repeats ^11-15 . This distinguishes such '4R' tauopathies from Pick's disease (the filaments of which are made of three-repeat (3R) tau isoforms) and from Alzheimer's disease and chronic traumatic encephalopathy (CTE) (in which both 3R and 4R isoforms are found in the filaments) ¹⁶ . Here we use cryo-electron microscopy to analyse the structures of tau filaments extracted from the brains of three individuals with CBD. These filaments were identical between cases, but distinct from those seen in Alzheimer's disease, Pick's disease and CTE ^17-19 . The core of a CBD filament comprises residues lysine 274 to glutamate 380 of tau, spanning the last residue of the R1 repeat, the whole of the R2, R3 and R4 repeats, and 12 amino acids after R4. The core adopts a previously unseen four-layered fold, which encloses a large nonproteinaceous density. This density is surrounded by the side chains of lysine residues 290 and 294 from R2 and lysine 370 from the sequence after R4.

---

Organizational Affiliation:

MRC Laboratory of Molecular Biology, Cambridge, UK. [e-mail].

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Microtubule-associated protein tau	A, B, C	441	Homo sapiens	Mutation(s): 0  Gene Names: MAPT, MAPTL, MTBT1, TAU
UniProt & NIH Common Fund Data Resources
Find proteins for P10636 (Homo sapiens) Explore P10636  Go to UniProtKB:  P10636
PHAROS:  P10636

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.20 Å
• Aggregation State: FILAMENT
• Reconstruction Method: HELICAL

Structure Validation

Entry History & Funding Information

Deposition Data

• Deposited Date: 2019-11-26
• Released Date: 2020-02-05
Deposition Author(s): Zhang, W., Murzin, A.G., Falcon, B., Shi, Y., Goedert, M., Scheres, S.H.W.

---

Funding Organization	Location	Grant Number
Medical Research Council (United Kingdom)	United Kingdom	MC_UP_A025_1013
Medical Research Council (United Kingdom)	United Kingdom	MC_U105184291

Revision History

• Version 1.0: 2020-02-05
  Type: Initial release

• Version 1.1: 2020-02-26
  Changes: Database references
• Version 1.2: 2020-04-22
  Changes: Database references
