6T0W

Human Influenza B polymerase recycling complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.18 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

A Structure-Based Model for the Complete Transcription Cycle of Influenza Polymerase.

Wandzik, J.M.Kouba, T.Karuppasamy, M.Pflug, A.Drncova, P.Provaznik, J.Azevedo, N.Cusack, S.

(2020) Cell 181: 877

  • DOI: https://doi.org/10.1016/j.cell.2020.03.061
  • Primary Citation of Related Structures:
    6SZU, 6SZV, 6T0N, 6T0R, 6T0S, 6T0U, 6T0V, 6T0W, 6T2C, 6TU5, 6TW1

  • PubMed Abstract:

    Influenza polymerase uses unique mechanisms to synthesize capped and polyadenylated mRNAs from the genomic viral RNA (vRNA) template, which is packaged inside ribonucleoprotein particles (vRNPs). Here, we visualize by cryoelectron microscopy the conformational dynamics of the polymerase during the complete transcription cycle from pre-initiation to termination, focusing on the template trajectory. After exiting the active site cavity, the template 3' extremity rebinds into a specific site on the polymerase surface. Here, it remains sequestered during all subsequent transcription steps, forcing the template to loop out as it further translocates. At termination, the strained connection between the bound template 5' end and the active site results in polyadenylation by stuttering at uridine 17. Upon product dissociation, further conformational changes release the trapped template, allowing recycling back into the pre-initiation state. Influenza polymerase thus performs transcription while tightly binding to and protecting both template ends, allowing efficient production of multiple mRNAs from a single vRNP.


  • Organizational Affiliation

    European Molecular Biology Laboratory, 71 Avenue des Martyrs, CS 90181, 38042 Grenoble Cedex 9, France.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Polymerase acidic protein751Influenza B virusMutation(s): 0
Gene Names: PA
EC: 3.1
UniProt
Find proteins for Q5V8Z9 (Influenza B virus)
Explore Q5V8Z9
Go to UniProtKB:  Q5V8Z9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5V8Z9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
RNA-directed RNA polymerase catalytic subunit772Influenza B virusMutation(s): 0
Gene Names: PB1
EC: 2.7.7.48
UniProt
Find proteins for Q5V8Y6 (Influenza B virus)
Explore Q5V8Y6
Go to UniProtKB:  Q5V8Y6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5V8Y6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Polymerase PB2799Influenza B virusMutation(s): 0
Gene Names: PB2
UniProt
Find proteins for Q5V8X3 (Influenza B virus)
Explore Q5V8X3
Go to UniProtKB:  Q5V8X3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5V8X3
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains LengthOrganismImage
vRNAD [auth V]34Influenza B virus
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.18 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
French National Research AgencyFranceANR-18-CE11-0028

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-15
    Type: Initial release
  • Version 1.1: 2020-04-29
    Changes: Database references
  • Version 1.2: 2020-05-27
    Changes: Database references
