6RAA | pdb_00006raa

CLK1 Kinase domain with bound imidazopyridin inhibitor TP003

PDB DOI: https://doi.org/10.2210/pdb6RAA/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2019-04-05 Released: 2019-04-24
Deposition Author(s): Schroeder, M., Arrowsmith, C., Knapp, S., Bountra, C., Edwards, A., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.233 (Depositor), 0.236 (DCC)
R-Value Work:
0.188 (Depositor), 0.194 (DCC)
R-Value Observed:
0.190 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6RAA

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

CLK1 Kinase domain with bound imidazopyridin inhibitor TP003

Schroeder, M., Arrowsmith, C., Knapp, S., Bountra, C., Edwards, A.

To be published.

Macromolecule Content

Total Structure Weight: 40.13 kDa
Atom Count: 3,016
Modeled Residue Count: 335
Deposited Residue Count: 339
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Dual specificity protein kinase CLK1	A	339	Homo sapiens	Mutation(s): 0 Gene Names: CLK1, CLK EC: 2.7.12.1
UniProt & NIH Common Fund Data Resources
Find proteins for P49759 (Homo sapiens) Explore P49759 Go to UniProtKB: P49759
PHAROS: P49759 GTEx: ENSG00000013441
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P49759
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
JWN Query on JWN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	4-[2-methyl-1-(4-methylpiperazin-1-yl)-1-oxidanylidene-propan-2-yl]-~{N}-(6-pyridin-4-ylimidazo[1,2-a]pyridin-2-yl)benzamide C₂₈ H₃₀ N₆ O₂ IEFFSHLHNYVSEF-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.233 (Depositor), 0.236 (DCC)
R-Value Work: 0.188 (Depositor), 0.194 (DCC)
R-Value Observed: 0.190 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 91.01	α = 90
b = 64.102	β = 117.64
c = 72.383	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
Aimless	data scaling
PHASER	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2019-04-24

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2019-04-24
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Refinement description
