6R3Y | pdb_00006r3y

M.tuberculosis nitrobindin with a cyanide molecule coordinated to the heme iron atom


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:
    0.202 (Depositor), 0.215 (DCC)
  • R-Value Work:
    0.178 (Depositor), 0.190 (DCC)
  • R-Value Observed:
    0.179 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 6R3Y

Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history

Literature

Mycobacterial and Human Nitrobindins: Structure and Function.

De Simone, G.di Masi, A.Vita, G.M.Polticelli, F.Pesce, A.Nardini, M.Bolognesi, M.Ciaccio, C.Coletta, M.Turilli, E.S.Fasano, M.Tognaccini, L.Smulevich, G.Abbruzzetti, S.Viappiani, C.Bruno, S.Ascenzi, P.

(2020) Antioxid Redox Signal 33: 229-246

  • DOI: https://doi.org/10.1089/ars.2019.7874
  • Primary Citation Related Structures:
    6R3W, 6R3Y

  • PubMed Abstract:

    Aims: Nitrobindins (Nbs) are evolutionary conserved all-β-barrel heme-proteins displaying a highly solvent-exposed heme-Fe(III) atom. The physiological role(s) of Nbs is almost unknown. Here, the structural and functional properties of ferric Mycobacterium tuberculosis Nb ( Mt -Nb(III)) and ferric Homo sapiens Nb ( Hs -Nb(III)) have been investigated and compared with those of ferric Arabidopsis thaliana Nb ( At -Nb(III), Rhodnius prolixus nitrophorins ( Rp -NP(III)s), and mammalian myoglobins. Results: Data here reported demonstrate that Mt -Nb(III), At -Nb(III), and Hs -Nb(III) share with Rp -NP(III)s the capability to bind selectively nitric oxide, but display a very low reactivity, if any, toward histamine. Data obtained overexpressing Hs -Nb in human embryonic kidney 293 cells indicate that Hs -Nb localizes mainly in the cytoplasm and partially in the nucleus, thanks to a nuclear localization sequence encompassing residues Glu124-Leu154. Human Hs -Nb corresponds to the C -terminal domain of the human nuclear protein THAP4 suggesting that Nb may act as a sensor possibly modulating the THAP4 transcriptional activity residing in the N -terminal region. Finally, we provide strong evidence that both Mt -Nb(III) and Hs -Nb(III) are able to scavenge peroxynitrite and to protect free l-tyrosine against peroxynitrite-mediated nitration. Innovation: Data here reported suggest an evolutionarily conserved function of Nbs related to their role as nitric oxide sensors and components of antioxidant systems. Conclusion: Human THAP4 may act as a sensing protein that couples the heme-based Nb(III) reactivity with gene transcription. Mt -Nb(III) seems to be part of the pool of proteins required to scavenge reactive nitrogen and oxygen species produced by the host during the immunity response.


  • Organizational Affiliation
    • Dipartimento di Scienze, Università Roma Tre, Roma, Italy.

Macromolecule Content

  • Total Structure Weight: 19.58 kDa
  • Atom Count: 1,367
  • Modeled Residue Count: 161
  • Deposited Residue Count: 172
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
UPF0678 fatty acid-binding protein-like protein ERS007657_00996172Mycobacterium tuberculosisMutation(s): 0
EC: 5.99
UniProt
Find proteins for P9WFG7 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv))
Explore P9WFG7
Go to UniProtKB:  P9WFG7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP9WFG7
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free:  0.202 (Depositor), 0.215 (DCC)
  • R-Value Work:  0.178 (Depositor), 0.190 (DCC)
  • R-Value Observed: 0.179 (Depositor)
Space Group: I 2 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.818α = 90
b = 74.383β = 90
c = 80.513γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-08
    Type: Initial release
  • Version 1.1: 2020-04-29
    Changes: Database references
  • Version 1.2: 2020-07-15
    Changes: Database references
  • Version 1.3: 2024-01-24
    Changes: Data collection, Database references, Refinement description
  • Version 1.4: 2024-11-06
    Changes: Structure summary
