Crystal structure of the first bromodomain of human BRD4 in complex with the inhibitor 16k

Experimental Data Snapshot

  • Resolution: 2.00 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.172
  • R-Value Observed: 0.174

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Designing Dual Inhibitors of Anaplastic Lymphoma Kinase (ALK) and Bromodomain-4 (BRD4) by Tuning Kinase Selectivity.

Watts, E.Heidenreich, D.Tucker, E.Raab, M.Strebhardt, K.Chesler, L.Knapp, S.Bellenie, B.Hoelder, S.

(2019) J Med Chem 62: 2618-2637

  • DOI: https://doi.org/10.1021/acs.jmedchem.8b01947
  • Primary Citation of Related Structures:
    6Q3Y, 6Q3Z

  • PubMed Abstract:

    Concomitant inhibition of anaplastic lymphoma kinase (ALK) and bromodomain-4 (BRD4) is a potential therapeutic strategy for targeting two key oncogenic drivers that co-segregate in a significant fraction of high-risk neuroblastoma patients, mutation of ALK and amplification of MYCN. Starting from known dual polo-like kinase (PLK)-1-BRD4 inhibitor BI-2536, we employed structure-based design to redesign this series toward compounds with a dual ALK-BRD4 profile. These efforts led to compound ( R)-2-((2-ethoxy-4-(1-methylpiperidin-4-yl)phenyl)amino)-7-ethyl-5-methyl-8-((4-methylthiophen-2-yl)methyl)-7,8-dihydropteridin-6(5 H)-one (16k) demonstrating improved ALK activity and significantly reduced PLK-1 activity, while maintaining BRD4 activity and overall kinome selectivity. We demonstrate the compounds' on-target engagement with ALK and BRD4 in cells as well as favorable broad kinase and bromodomain selectivity.

  • Organizational Affiliation

    Department of Gynecology and Obstetrics , Johann Wolfgang Goethe-University , Theodor-Stern Kai 7 , 60590 Frankfurt am Main , Germany.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bromodomain-containing protein 4
A, B
127Homo sapiensMutation(s): 0
Gene Names: BRD4HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens)
Explore O60885
Go to UniProtKB:  O60885
GTEx:  ENSG00000141867
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO60885
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on HG8

Download Ideal Coordinates CCD File
C [auth A],
H [auth B]
C29 H38 N6 O2 S
Query on EDO

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
G [auth A]
I [auth B]
D [auth A],
E [auth A],
F [auth A],
G [auth A],
I [auth B],
J [auth B],
K [auth B]
C2 H6 O2
Binding Affinity Annotations
IDSourceBinding Affinity
HG8 Binding MOAD:  6Q3Z Kd: 44 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.00 Å
  • R-Value Free: 0.231
  • R-Value Work: 0.172
  • R-Value Observed: 0.174
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 30.151α = 84.38
b = 39.511β = 75.19
c = 55.721γ = 89.96
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-06
    Type: Initial release
  • Version 1.1: 2019-03-27
    Changes: Data collection, Database references
  • Version 1.2: 2024-01-24
    Changes: Data collection, Database references, Refinement description
