6OOW

The crystal structure of 4-ethylbenzoate bound to T252A mutant of CYP199A4

• PDB DOI: https://doi.org/10.2210/pdb6OOW/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Rhodopseudomonas palustris HaA2
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2019-04-23 Released: 2020-04-29
• Deposition Author(s): Coleman, T., Bruning, J.B., Bell, S.G.
• Funding Organization(s): Australian Research Council (ARC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.168
• R-Value Work: 0.142
• R-Value Observed: 0.144

Literature

Structural investigation of the interplay between the substrate and the acid-alcohol pair of residues in cytochrome P450 enzymes

Coleman, T., Bruning, J.B., Bell, S.G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 43.67 kDa
• Atom Count: 3,657
• Modelled Residue Count: 393
• Deposited Residue Count: 393
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cytochrome P450	A	393	Rhodopseudomonas palustris HaA2	Mutation(s): 1  Gene Names: RPB_3613
UniProt
Find proteins for Q2IU02 (Rhodopseudomonas palustris (strain HaA2)) Explore Q2IU02  Go to UniProtKB:  Q2IU02

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
HEM	C [auth A]	PROTOPORPHYRIN IX CONTAINING FE C34 H32 Fe N4 O4 KABFMIBPWCXCRK-RGGAHWMASA-L
EGM (Subject of Investigation/LOI)	D [auth A]	4-ethylbenzoic acid C9 H10 O2 ZQVKTHRQIXSMGY-UHFFFAOYSA-N
CL	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.60 Å
• R-Value Free: 0.168
• R-Value Work: 0.142
• R-Value Observed: 0.144
• Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.03	α = 90
b = 51.41	β = 92.05
c = 79.14	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
MOSFLM	data reduction
Aimless	data scaling
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

Currently 6OOW does not have a validation slider image.

Entry History & Funding Information

Deposition Data

• Released Date: 2020-04-29
Deposition Author(s): Coleman, T., Bruning, J.B., Bell, S.G.

---

Funding Organization	Location	Grant Number
Australian Research Council (ARC)	Australia	DP140103229

Revision History

• Version 1.0: 2020-04-29
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Data collection, Database references, Refinement description
