6OH6

Crystal structure of (E)-biformene synthase LrdC from Streptomyces sp. strain K155 in complex with Mg and PPi


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.07 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.233
  • R-Value Observed: 0.234

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

The structure of (E)-biformene synthase provides insights into the biosynthesis of bacterial bicyclic labdane-related diterpenoids.

Centeno-Leija, S.Tapia-Cabrera, S.Guzman-Trampe, S.Esquivel, B.Esturau-Escofet, N.Tierrafria, V.H.Rodriguez-Sanoja, R.Zarate-Romero, A.Stojanoff, V.Rudino-Pinera, E.Sanchez, S.Serrano-Posada, H.

(2019) J Struct Biol 207: 29-39

  • DOI: https://doi.org/10.1016/j.jsb.2019.04.010
  • Primary Citation of Related Structures:
    6OH6, 6OH7, 6OH8

  • PubMed Abstract:

    The labdane-related diterpenoids (LRDs) are a large group of natural products with a broad range of biological activities. They are synthesized through two consecutive reactions catalyzed by class II and I diterpene synthases (DTSs). The structural complexity of LRDs mainly depends on the catalytic activity of class I DTSs, which catalyze the formation of bicyclic to pentacyclic LRDs, using as a substrate the catalytic product of class II DTSs. To date, the structural and mechanistic details for the biosynthesis of bicyclic LRDs skeletons catalyzed by class I DTSs remain unclear. This work presents the first X-ray crystal structure of an (E)-biformene synthase, LrdC, from the soil bacterium Streptomyces sp. strain K155. LrdC was identified as a part of an LRD cluster of five genes and was found to be a class I DTS that catalyzes the Mg 2+ -dependent synthesis of bicyclic LRD (E)-biformene by the dephosphorylation and rearrangement of normal copalyl pyrophosphate (CPP). Structural analysis of LrdC coupled with docking studies suggests that Phe189 prevents cyclization beyond the bicyclic LRD product through a strong stabilization of the allylic carbocation intermediate, while Tyr317 functions as a general base catalyst to deprotonate the CPP substrate. Structural comparisons of LrdC with homology models of bacterial bicyclic LRD-forming enzymes (CldD, RmnD and SclSS), as well as with the crystallographic structure of bacterial tetracyclic LRD ent-kaurene synthase (BjKS), provide further structural insights into the biosynthesis of bacterial LRD natural products.


  • Organizational Affiliation

    Consejo Nacional de Ciencia y Tecnología, Laboratorio de Agrobiotecnología, Tecnoparque CLQ, Universidad de Colima, Carretera Los Limones-Loma de Juárez, 28629 Colima, Colima, Mexico. Electronic address: scenteno0@ucol.mx.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Labdane-related diterpene synthase342Streptomyces sp.Mutation(s): 0
EC: 4.2.3.193
UniProt
Find proteins for A0A158RFK9 (Streptomyces sp)
Explore A0A158RFK9
Go to UniProtKB:  A0A158RFK9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A158RFK9
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PPV
Query on PPV

Download Ideal Coordinates CCD File
B [auth A]PYROPHOSPHATE
H4 O7 P2
XPPKVPWEQAFLFU-UHFFFAOYSA-N
PEG
Query on PEG

Download Ideal Coordinates CCD File
G [auth A],
H [auth A],
I [auth A]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
F [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
C [auth A],
D [auth A],
E [auth A]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.07 Å
  • R-Value Free: 0.253
  • R-Value Work: 0.233
  • R-Value Observed: 0.234
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 107.05α = 90
b = 107.05β = 90
c = 88.821γ = 120
Software Package:
Software NamePurpose
Aimlessdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
MOSFLMdata reduction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Consejo Nacional de Ciencia y Tecnologia (CONACYT)MexicoCB-2016-01-285001
Consejo Nacional de Ciencia y Tecnologia (CONACYT)MexicoINFR-2017-01-280608

Revision History  (Full details and data files)

  • Version 1.0: 2019-04-17
    Type: Initial release
  • Version 1.1: 2019-04-24
    Changes: Data collection, Database references
  • Version 1.2: 2019-06-19
    Changes: Data collection, Database references
  • Version 1.3: 2020-01-15
    Changes: Author supporting evidence
  • Version 1.4: 2024-03-13
    Changes: Data collection, Database references, Derived calculations
  • Version 1.5: 2024-04-03
    Changes: Refinement description
