6NJK | pdb_00006njk

Crystal structure of beta-lactamase from Sulfitobacter sp. EE-36

• PDB DOI: https://doi.org/10.2210/pdb6NJK/pdb

• Classification: HYDROLASE
• Organism(s): Sulfitobacter sp. EE-36
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2019-01-03 Released: 2019-01-16
• Deposition Author(s): Michalska, K., Tesar, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:
  0.177 (Depositor), 0.180 (DCC)
• R-Value Work:
  0.143 (Depositor), 0.140 (DCC)
• R-Value Observed:
  0.143 (Depositor)

Literature

Crystal structure of beta-lactamase from Sulfitobacter sp. EE-36

Michalska, K., Tesar, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 79.44 kDa
• Atom Count: 6,055
• Modeled Residue Count: 725
• Deposited Residue Count: 734
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
beta-lactamase	A, B	367	Sulfitobacter sp. EE-36	Mutation(s): 0  Gene Names: EE36_13938

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ACT	C [auth A]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A, B	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:  0.177 (Depositor), 0.180 (DCC)
• R-Value Work:  0.143 (Depositor), 0.140 (DCC)
• R-Value Observed: 0.143 (Depositor)

Diffraction Data: https://doi.org/10.18430/m36njk

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.694	α = 90
b = 107.39	β = 91.77
c = 59.457	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2019-01-16
Deposition Author(s): Michalska, K., Tesar, C., Endres, M., Joachimiak, A., Center for Structural Genomics of Infectious Diseases (CSGID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	HHSN272201700060C

Revision History

• Version 1.0: 2019-01-16
  Type: Initial release

• Version 1.1: 2019-12-18
  Changes: Author supporting evidence
• Version 1.2: 2024-10-23
  Changes: Data collection, Database references, Structure summary
