Crystal structure of SbnH in complex with citryl-diaminoethane

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.221
  • R-Value Observed: 0.222

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Structural Insights into Substrate Recognition and Activity Regulation of the Key Decarboxylase SbnH in Staphyloferrin B Biosynthesis.

Tang, J.Ju, Y.Gu, Q.Xu, J.Zhou, H.

(2019) J Mol Biol 431: 4868-4881

  • DOI: https://doi.org/10.1016/j.jmb.2019.10.009
  • Primary Citation of Related Structures:
    6KNH, 6KNI, 6KNK

  • PubMed Abstract:

    Staphyloferrin B is a hydroxycarboxylate siderophore that is crucial for the invasion and virulence of Staphylococcus aureus in mammalian hosts where free iron ions are scarce. The assembly of staphyloferrin B involves four enzymatic steps, in which SbnH, a pyridoxal 5'-phosphate (PLP)-dependent decarboxylase, catalyzes the second step. Here, we report the X-ray crystal structures of S. aureus SbnH (SaSbnH) in complex with PLP, citrate, and the decarboxylation product citryl-diaminoethane (citryl-Dae). The overall structure of SaSbnH resembles those of the previously reported PLP-dependent amino acid decarboxylases, but the active site of SaSbnH showed unique structural features. Structural and mutagenesis analysis revealed that the citryl moiety of the substrate citryl-l-2,3-diaminopropionic acid (citryl-l-Dap) inserts into a narrow groove at the dimer interface of SaSbnH and forms hydrogen bonding interactions with both subunits. In the active site, a conserved lysine residue forms an aldimine linkage with the cofactor PLP, and a phenylalanine residue is essential for accommodating the l-configuration Dap of the substrate. Interestingly, the freestanding citrate molecule was found to bind to SaSbnH in a conformation inverse to that of the citryl group of citryl-Dae and efficiently inhibit SaSbnH. As an intermediate in the tricarboxylic acid (TCA) cycle, citrate is highly abundant in bacterial cells until iron depletion; thus, its inhibition of SaSbnH may serve as an iron-dependent regulatory mechanism in staphyloferrin B biosynthesis.

  • Organizational Affiliation

    Research Center for Drug Discovery, School of Pharmaceutical Sciences, Sun Yat-sen University, Guangzhou 510006, China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Probable diaminopimelate decarboxylase protein
A, B, C
406Staphylococcus aureus subsp. aureus Mu50Mutation(s): 1
Gene Names: SAV0123
Find proteins for A0A0H3JPF2 (Staphylococcus aureus (strain Mu50 / ATCC 700699))
Explore A0A0H3JPF2
Go to UniProtKB:  A0A0H3JPF2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0H3JPF2
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
DN9 (Subject of Investigation/LOI)
Query on DN9

Download Ideal Coordinates CCD File
D [auth A](2~{S})-2-[2-[2-[[2-methyl-3-oxidanyl-5-(phosphonooxymethyl)pyridin-4-yl]methylamino]ethylamino]-2-oxidanylidene-ethyl]-2-oxidanyl-butanedioic acid
C16 H24 N3 O11 P
X3J (Subject of Investigation/LOI)
Query on X3J

Download Ideal Coordinates CCD File
C8 H14 N2 O6
Query on PO4

Download Ideal Coordinates CCD File
E [auth B],
G [auth C]
O4 P
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.221
  • R-Value Observed: 0.222
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 176.299α = 90
b = 80.325β = 102.07
c = 111.524γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Ministry of Science and Technology (China)China2017YFE0109900
National Natural Science Foundation of ChinaChinaNo. 81773636

Revision History  (Full details and data files)

  • Version 1.0: 2019-11-13
    Type: Initial release
  • Version 1.1: 2020-01-01
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
