6JTL | pdb_00006jtl

Crystal structure of NagZ from Neisseria gonorrhoeae in complex with zinc ion

• PDB DOI: https://doi.org/10.2210/pdb6JTL/pdb

• Classification: HYDROLASE
• Organism(s): Neisseria gonorrhoeae
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2019-04-11 Released: 2020-05-13
• Deposition Author(s): Chen, Y.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.249 (Depositor), 0.253 (DCC)
• R-Value Work:
  0.203 (Depositor), 0.208 (DCC)
• R-Value Observed:
  0.205 (Depositor)

Starting Model: experimental

Literature

Crystal structure of NagZ from Neisseria gonorrhoeae in complex with zinc ion

Chen, Y.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 86.07 kDa
• Atom Count: 5,381
• Modeled Residue Count: 670
• Deposited Residue Count: 794
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-hexosaminidase	A, B	397	Neisseria gonorrhoeae	Mutation(s): 0  Gene Names: nagZ, NGO0135 EC: 3.2.1.52
UniProt
Find proteins for Q5FA94 (Neisseria gonorrhoeae (strain ATCC 700825 / FA 1090)) Explore Q5FA94  Go to UniProtKB:  Q5FA94

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN (Subject of Investigation/LOI)	C [auth A], D [auth A], E [auth B], F [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.249 (Depositor), 0.253 (DCC)
• R-Value Work:  0.203 (Depositor), 0.208 (DCC)
• R-Value Observed: 0.205 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.805	α = 90
b = 90.992	β = 90
c = 103.325	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2020-05-13
Deposition Author(s): Chen, Y.

Revision History

• Version 1.0: 2020-05-13
  Type: Initial release

• Version 1.1: 2023-11-22
  Changes: Data collection, Database references, Derived calculations, Refinement description
