Crystal structure of Flavin-dependent Monooxygenase HadA

Experimental Data Snapshot

  • Resolution: 2.30 Å
  • R-Value Free: 0.261
  • R-Value Work: 0.200
  • R-Value Observed: 0.203

wwPDB Validation   3D Report Full Report

This is version 1.2 of the entry. See complete history


Identification of a Hotspot Residue for Improving the Thermostability of a Flavin-Dependent Monooxygenase.

Pongpamorn, P.Watthaisong, P.Pimviriyakul, P.Jaruwat, A.Lawan, N.Chitnumsub, P.Chaiyen, P.

(2019) Chembiochem 20: 3020-3031

  • DOI: https://doi.org/10.1002/cbic.201900413
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    HadA is a flavin-dependent monooxygenase that can catalyze the denitration and dehalogenation of a wide variety of toxicants such as pesticides. Although these enzymatic reactions are useful for bioremediation or biocatalysis, the application of HadA for these purposes is not yet possible because of its low thermostability. In this work we have engineered HadA to be more thermostable through the use of structural, in silico, and rational approaches. The X-ray structure of HadA was solved to obtain a reliable three-dimensional protein model for further prediction of thermostable variants. In silico analysis by using two bioinformatic tools-FireProt and Disulfide by Design-suggested 102 variants that we then further refined by applying rational criteria including the location of a particular residue and its nearby interactions, as well as other biophysical parameters to narrow down the list to six candidates. The G513Y variant was found to be an optimal engineered candidate because it has significantly improved stability relative to the wild-type enzyme and equivalent activity. G513Y has an activity half-life 72 (50 °C) and 160 times (45 °C) longer than that of the wild-type enzyme. Coupled together with thermostable reactions of reduced flavin and NADH-regenerating systems, the G513Y variant can be used to catalyze denitration of 4nitrophenol at 45 °C. Structure/sequence alignments of HadA and its homologues indicate that several flavin-dependent monooxygenases also contain amino acid residues homologous to the G513 of HadA, hence opening up the possibility of applying this engineering approach to improving their thermostabilities as well. Molecular dynamics (MD) simulations confirmed that the improved thermostability of the G513Y variant was due to aromatic hydrocarbon interactions between Y513 and N359, L347, G348, and F349.

  • Organizational Affiliation

    Department of Chemistry, Faculty of Science, Chiang Mai University, Chiang Mai, 50200, Thailand.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Chlorophenol monooxygenase
A, B, C, D
517Ralstonia pickettii DTP0602Mutation(s): 0
Gene Names: hadA
Find proteins for Q53008 (Ralstonia pickettii)
Explore Q53008
Go to UniProtKB:  Q53008
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ53008
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.30 Å
  • R-Value Free: 0.261
  • R-Value Work: 0.200
  • R-Value Observed: 0.203
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 97.924α = 90
b = 128.143β = 90
c = 182.182γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PDB_EXTRACTdata extraction
PROTEUM PLUSdata reduction

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-11-06
    Type: Initial release
  • Version 1.1: 2020-01-01
    Changes: Database references
  • Version 1.2: 2023-11-22
    Changes: Data collection, Database references, Refinement description
