6IVX

Discovery of the Second Generation ROR gamma Inhibitors Composed of an Azole Scaffold.

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.35 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.182
  • R-Value Observed: 0.183

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history.


Literature

Discovery of Second Generation ROR gamma Inhibitors Composed of an Azole Scaffold.

Kotoku, M., Maeba, T., Fujioka, S., Yokota, M., Seki, N., Ito, K., Suwa, Y., Ikenogami, T., Hirata, K., Hase, Y., Katsuda, Y., Miyagawa, N., Arita, K., Asahina, K., Noguchi, M., Nomura, A., Doi, S., Adachi, T., Crowe, P., Tao, H., Thacher, S., Hashimoto, H., Suzuki, T., Shiozaki, M.

(2019) J Med Chem 62: 2837-2842

  • DOI: https://doi.org/10.1021/acs.jmedchem.8b01567
  • Primary Citation of Related Structures:
    6IVX

  • PubMed Abstract:

    • Starting from a previously reported RORγ inhibitor (1), successive efforts to improve in vivo potency were continued. Introduction of metabolically beneficial motifs in conjunction with scaffold hopping was examined, resulting in discovery of the second generation RORγ inhibitor composed of a 4-(isoxazol-3-yl)butanoic acid scaffold (24) ...

    Starting from a previously reported RORγ inhibitor (1), successive efforts to improve in vivo potency were continued. Introduction of metabolically beneficial motifs in conjunction with scaffold hopping was examined, resulting in discovery of the second generation RORγ inhibitor composed of a 4-(isoxazol-3-yl)butanoic acid scaffold (24). Compound 24 achieved a 10-fold improvement in in vivo potency in a mouse CD3 challenge model along with significant anti-inflammatory effects in a mouse dermatitis model.

    Organizational Affiliation:

    Graduate School of Medical Science , Kyoto Prefectural University of Medicine , 1-5 Shimogamo-hangi-cho , Sakyo-ku , Kyoto 603-0823 , Japan.



Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Nuclear receptor ROR-gamma
A, C, E, G
258Homo sapiensMutation(s): 2
Gene Names: RORG, RORC, NR1F3, RZRG
UniProt & NIH Common Fund Data Resources
Find proteins for P51449 (Homo sapiens)
Explore P51449
Go to UniProtKB:  P51449
PHAROS:  P51449
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP51449
Protein Feature View
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Nuclear receptor corepressor 2
B, D, F, H
22Homo sapiensMutation(s): 0
Gene Names: NCOR2, CTG26
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y618 (Homo sapiens)
Explore Q9Y618
Go to UniProtKB:  Q9Y618
PHAROS:  Q9Y618
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9Y618
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
AYO
Query on AYO
Download Ideal Coordinates CCD File
I [auth A],
J [auth C],
K [auth E],
L [auth G]		(4S)-4-[4'-cyclopropyl-5-(2,2-dimethylpropyl)[3,5'-bi-1,2-oxazol]-3'-yl]-6-[(2,4-dichlorophenyl)amino]-6-oxohexanoic acid
C26 H29 Cl2 N3 O5
DGQSIRLZPGLPLS-HNNXBMFYSA-N		 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.35 Å
  • R-Value Free: 0.198
  • R-Value Work: 0.182
  • R-Value Observed: 0.183
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 79.285α = 90
b = 72.555β = 90.01
c = 98.88γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data
Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-06
    Type: Initial release
  • Version 1.1: 2019-03-13
    Changes: Data collection, Database references
  • Version 1.2: 2019-03-27
    Changes: Data collection, Database references
