6HA6 | pdb_00006ha6

Factor Inhibiting HIF (FIH) in complex with zinc, NOG and TRPV3 (220-246)

PDB DOI: https://doi.org/10.2210/pdb6HA6/pdb

Classification: GENE REGULATION
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2018-08-07 Released: 2019-08-28
Deposition Author(s): Leissing, T.M., Clifton, I.J., Saward, B.G., Lu, X., Hopkinson, R.J., Schofield, C.J.
Funding Organization(s): Engineering and Physical Sciences Research Council

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.98 Å
R-Value Free:
0.203 (Depositor), 0.211 (DCC)
R-Value Work:
0.181 (Depositor), 0.195 (DCC)
R-Value Observed:
0.182 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Factor Inhibiting HIF (FIH) in complex with zinc, NOG and TRPV3 (220-246)

Leissing, T.M., Clifton, I.J., Saward, B.G., Lu, X., Hopkinson, R.J., Schofield, C.J.

To be published.

Macromolecule Content

Total Structure Weight: 43.98 kDa
Atom Count: 3,003
Modeled Residue Count: 354
Deposited Residue Count: 376
Unique protein chains: 2

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hypoxia-inducible factor 1-alpha inhibitor	A	349	Homo sapiens	Mutation(s): 0 Gene Names: HIF1AN, FIH1 EC: 1.14.11.30 (PDB Primary Data), 1.14.11 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NWT6 (Homo sapiens) Explore Q9NWT6 Go to UniProtKB: Q9NWT6
PHAROS: Q9NWT6 GTEx: ENSG00000166135
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9NWT6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Transient receptor potential cation channel subfamily V member 3	B [auth D]	27	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q8NET8 (Homo sapiens) Explore Q8NET8 Go to UniProtKB: Q8NET8
PHAROS: Q8NET8 GTEx: ENSG00000167723
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8NET8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
OGA Query on OGA Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	N-OXALYLGLYCINE C₄ H₅ N O₅ BIMZLRFONYSTPT-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	D [auth A], E [auth A], F [auth A], G [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A]	H [auth A], I [auth A], J [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain K [auth A] MOL2 format, chain K [auth A] mmCIF format, chain K [auth A]	K [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Interactions & Density Focus chain K [auth A]
