Receptor-binding domain of Proteus mirabilis Uroepithelial Cell Adhesin UcaD21-211

Experimental Data Snapshot

  • Resolution: 1.70 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.197
  • R-Value Observed: 0.198

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Structures of two fimbrial adhesins, AtfE and UcaD, from the uropathogen Proteus mirabilis.

Jiang, W.Ubhayasekera, W.Pearson, M.M.Knight, S.D.

(2018) Acta Crystallogr D Struct Biol 74: 1053-1062

  • DOI: https://doi.org/10.1107/S2059798318012391
  • Primary Citation of Related Structures:
    6H1Q, 6H1X, 6H2L

  • PubMed Abstract:

    The important uropathogen Proteus mirabilis encodes a record number of chaperone/usher-pathway adhesive fimbriae. Such fimbriae, which are used for adhesion to cell surfaces/tissues and for biofilm formation, are typically important virulence factors in bacterial pathogenesis. Here, the structures of the receptor-binding domains of the tip-located two-domain adhesins UcaD (1.5 Å resolution) and AtfE (1.58 Å resolution) from two P. mirabilis fimbriae (UCA/NAF and ATF) are presented. The structures of UcaD and AtfE are both similar to the F17G type of tip-located fimbrial receptor-binding domains, and the structures are very similar despite having only limited sequence similarity. These structures represent an important step towards a molecular-level understanding of P. mirabilis fimbrial adhesins and their roles in the complex pathogenesis of urinary-tract infections.

  • Organizational Affiliation

    Department of Microbiology and Immunology, University of Michigan Medical School, 5641 Medical Science Building II, 1150 West Medical Center Drive, Ann Arbor, MI 48109-0620, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative fimbrial adhesin198Proteus mirabilis HI4320Mutation(s): 0
Gene Names: PMI0533
Find proteins for B4EV65 (Proteus mirabilis (strain HI4320))
Explore B4EV65
Go to UniProtKB:  B4EV65
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB4EV65
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.70 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.197
  • R-Value Observed: 0.198
  • Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.35α = 90
b = 73.35β = 90
c = 153.106γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Swedish Research CouncilSweden--

Revision History  (Full details and data files)

  • Version 1.0: 2018-11-07
    Type: Initial release
  • Version 1.1: 2018-11-14
    Changes: Data collection, Database references
