Structure of amide bond synthetase Mcba K483A mutant from Marinactinospora thermotolerans

Experimental Data Snapshot

  • Resolution: 2.80 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.204
  • R-Value Observed: 0.206

wwPDB Validation   3D Report Full Report

This is version 2.1 of the entry. See complete history


The Broad Aryl Acid Specificity of the Amide Bond Synthetase McbA Suggests Potential for the Biocatalytic Synthesis of Amides.

Petchey, M.Cuetos, A.Rowlinson, B.Dannevald, S.Frese, A.Sutton, P.W.Lovelock, S.Lloyd, R.C.Fairlamb, I.J.S.Grogan, G.

(2018) Angew Chem Int Ed Engl 57: 11584-11588

  • DOI: https://doi.org/10.1002/anie.201804592
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Amide bond formation is one of the most important reactions in pharmaceutical synthetic chemistry. The development of sustainable methods for amide bond formation, including those that are catalyzed by enzymes, is therefore of significant interest. The ATP-dependent amide bond synthetase (ABS) enzyme McbA, from Marinactinospora thermotolerans, catalyzes the formation of amides as part of the biosynthetic pathway towards the marinacarboline secondary metabolites. The reaction proceeds via an adenylate intermediate, with both adenylation and amidation steps catalyzed within one active site. In this study, McbA was applied to the synthesis of pharmaceutical-type amides from a range of aryl carboxylic acids with partner amines provided at 1-5 molar equivalents. The structure of McbA revealed the structural determinants of aryl acid substrate tolerance and differences in conformation associated with the two half reactions catalyzed. The catalytic performance of McbA, coupled with the structure, suggest that this and other ABS enzymes may be engineered for applications in the sustainable synthesis of pharmaceutically relevant (chiral) amides.

  • Organizational Affiliation

    Current address: School of Chemistry, University of Manchester, Manchester Institute of Biotechnology, 131 Princess Street, Manchester, M1 7DN, UK.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Fatty acid CoA ligase
A, B, C, D, E
499Marinactinospora thermotoleransMutation(s): 1
Find proteins for R4R1U5 (Marinactinospora thermotolerans)
Explore R4R1U5
Go to UniProtKB:  R4R1U5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupR4R1U5
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
AMP (Subject of Investigation/LOI)
Query on AMP

Download Ideal Coordinates CCD File
F [auth A],
H [auth B],
J [auth C],
L [auth D],
N [auth E]
C10 H14 N5 O7 P
EQ2 (Subject of Investigation/LOI)
Query on EQ2

Download Ideal Coordinates CCD File
G [auth A],
I [auth B],
K [auth C],
M [auth D],
O [auth E]
1-ethanoyl-9~{H}-pyrido[3,4-b]indole-3-carboxylic acid
C14 H10 N2 O3
Experimental Data & Validation

Experimental Data

  • Resolution: 2.80 Å
  • R-Value Free: 0.248
  • R-Value Work: 0.204
  • R-Value Observed: 0.206
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 118.234α = 90
b = 130.738β = 90
c = 196.383γ = 90
Software Package:
Software NamePurpose
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-09-05
    Type: Initial release
  • Version 2.0: 2019-10-02
    Changes: Advisory, Atomic model, Data collection, Database references, Derived calculations, Other, Polymer sequence, Source and taxonomy, Structure summary
  • Version 2.1: 2023-03-08
    Changes: Advisory, Database references
