6GLQ | pdb_00006glq

Crystal structure of hMTH1 N33G in complex with LW14 in the absence of acetate

PDB DOI: https://doi.org/10.2210/pdb6GLQ/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2018-05-23 Released: 2019-02-20
Deposition Author(s): Eberle, S.A., Wiedmer, L., Sledz, P., Caflisch, A.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.210 (Depositor), 0.210 (DCC)
R-Value Work:
0.172 (Depositor), 0.173 (DCC)
R-Value Observed:
0.174 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6GLQ

This is version 1.1 of the entry. See complete history.

Literature

hMTH1 N33G in complex with LW14.

Eberle, S.A., Wiedmer, L., Sledz, P., Caflisch, A.

To be published.

Macromolecule Content

Total Structure Weight: 43.23 kDa
Atom Count: 2,964
Modeled Residue Count: 316
Deposited Residue Count: 364
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
7,8-dihydro-8-oxoguanine triphosphatase	A, B	182	Homo sapiens	Mutation(s): 1 Gene Names: NUDT1, MTH1 EC: 3.6.1.55 (PDB Primary Data), 3.6.1.56 (PDB Primary Data), 3.6.1 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P36639 (Homo sapiens) Explore P36639 Go to UniProtKB: P36639
PHAROS: P36639 GTEx: ENSG00000106268
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P36639
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
BU8 Query on BU8 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain H [auth B] MOL2 format, chain C [auth A] MOL2 format, chain H [auth B] mmCIF format, chain C [auth A] mmCIF format, chain H [auth B]	C [auth A], H [auth B]	1~{H}-imidazo[4,5-b]pyridin-2-amine C₆ H₆ N₄ KXQPVJRJUJJWQJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain H [auth B]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth B] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain L [auth B] SDF format, chain M [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain L [auth B] MOL2 format, chain M [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain L [auth B] mmCIF format, chain M [auth B]	D [auth A] E [auth A] F [auth A] G [auth A] I [auth B] D [auth A], E [auth A], F [auth A], G [auth A], I [auth B], J [auth B], K [auth B], L [auth B], M [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B]

Binding Affinity Annotations
ID	Source	Binding Affinity
BU8	BindingDB: 6GLQ	Kd: 1300 (nM) from 1 assay(s)
BU8	BindingDB: 6GLQ	IC50: 1100 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free: 0.210 (Depositor), 0.210 (DCC)
R-Value Work: 0.172 (Depositor), 0.173 (DCC)
R-Value Observed: 0.174 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.698	α = 90
b = 47.692	β = 90
c = 124.073	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2019-02-20

Deposition Author(s):

Funding Organization	Location	Grant Number
	Switzerland	FK-16-032

Revision History (Full details and data files)

Version 1.0: 2019-02-20
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Database references, Structure summary
