6FVI | pdb_00006fvi

ASH / PapD-like domain of human CEP192 (PapD-like domain 7)

PDB DOI: https://doi.org/10.2210/pdb6FVI/pdb

Classification: CELL CYCLE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2018-03-02 Released: 2019-03-20
Deposition Author(s): Kovalevskiy, O.V., van Breugel, M.
Funding Organization(s): Medical Research Council (United Kingdom)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.00 Å
R-Value Free:
0.152 (Depositor), 0.152 (DCC)
R-Value Work:
0.136 (Depositor), 0.136 (DCC)
R-Value Observed:
0.137 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6FVI

This is version 1.1 of the entry. See complete history.

Literature

ASH / PapD-like domain of human CEP192 (PapD-like domain 7)

Kovalevskiy, O., van Breugel, M.

To be published.

Macromolecule Content

Total Structure Weight: 16.99 kDa
Atom Count: 1,681
Modeled Residue Count: 142
Deposited Residue Count: 151
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Centrosomal protein of 192 kDa	A	151	Homo sapiens	Mutation(s): 0 Gene Names: CEP192, KIAA1569, PP8407
UniProt & NIH Common Fund Data Resources
Find proteins for Q8TEP8 (Homo sapiens) Explore Q8TEP8 Go to UniProtKB: Q8TEP8
PHAROS: Q8TEP8 GTEx: ENSG00000101639
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8TEP8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.00 Å
R-Value Free: 0.152 (Depositor), 0.152 (DCC)
R-Value Work: 0.136 (Depositor), 0.136 (DCC)
R-Value Observed: 0.137 (Depositor)

Space Group: P 2 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 39.7	α = 90
b = 60.06	β = 90
c = 64.11	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
MOSFLM	data reduction
CRANK	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2019-03-20

Deposition Author(s):

Kovalevskiy, O.V.

van Breugel, M.

Funding Organization	Location	Grant Number
Medical Research Council (United Kingdom)	United Kingdom	MC_UP_1201/3

Revision History (Full details and data files)

Version 1.0: 2019-03-20
Type: Initial release
Version 1.1: 2024-11-13
Changes: Data collection, Database references, Refinement description, Structure summary
