6EGZ

Crystal structure of cytochrome c in complex with di-PEGylated sulfonatocalix[4]arene


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.17 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.203
  • R-Value Observed: 0.205

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.2 of the entry. See complete history


Literature

Noncovalent PEGylation via Sulfonatocalix[4]arene-A Crystallographic Proof.

Mummidivarapu, V.V.S.Rennie, M.L.Doolan, A.M.Crowley, P.B.

(2018) Bioconjug Chem 29: 3999-4003

  • DOI: 10.1021/acs.bioconjchem.8b00769
  • Primary Citation of Related Structures:
    6EGY, 6EGZ

  • PubMed Abstract:
  • Noncovalent or supramolecular PEGylation, in combination with the site of administration, has great potential to increase the half-life of therapeutic proteins. To date, a variety of noncovalent PEGylation strategies have been devised. However, questions remain concerning the nature of the protein-PEG interaction ...

    Noncovalent or supramolecular PEGylation, in combination with the site of administration, has great potential to increase the half-life of therapeutic proteins. To date, a variety of noncovalent PEGylation strategies have been devised. However, questions remain concerning the nature of the protein-PEG interaction. Here, we report structural analyses of a model system that comprised the lysine-rich cytochrome c and two PEGylated variants of sulfonatocalix[4]arene. Complex formation was characterized in solution by NMR spectroscopy. It was found that mono- or di-PEGylated sulfonatocalix[4]arene bound the protein similar to the parent calixarene. X-ray crystal structures at <2.7 Å resolution of the PEGylated derivatives in complex with cytochrome c revealed that the PEG chains were mostly disordered or encapsulated within the calixarene cavity. These results suggest that there was minimal interaction between the PEG and the protein surface, providing further evidence in favor of PEG maintaining a random coil conformation.


    Organizational Affiliation

    School of Chemistry , National University of Ireland Galway , University Road , H91 TK33 , Galway , Ireland.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c iso-1A, B108Saccharomyces cerevisiaeMutation(s): 2
Gene Names: CYC1YJR048WJ1653
UniProt
Find proteins for P00044 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00044
Go to UniProtKB:  P00044
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00044
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.17 Å
  • R-Value Free: 0.247
  • R-Value Work: 0.203
  • R-Value Observed: 0.205
  • Space Group: I 41 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 147.961α = 90
b = 147.961β = 90
c = 147.961γ = 90
Software Package:
Software NamePurpose
XDSdata collection
XSCALEdata scaling
PHASERphasing
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ireland13/CDA/2168

Revision History  (Full details and data files)

  • Version 1.0: 2018-10-10
    Type: Initial release
  • Version 1.1: 2018-11-28
    Changes: Data collection, Database references, Structure summary
  • Version 2.0: 2019-01-23
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
  • Version 2.1: 2019-04-24
    Changes: Advisory, Data collection, Database references
  • Version 2.2: 2019-08-28
    Changes: Advisory, Data collection
