6DGC

Crystal structure of the C-terminal catalytic domain of ISC1926 TnpA, an IS607-like serine recombinase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.92 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.217
  • R-Value Observed: 0.220

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Multiple serine transposase dimers assemble the transposon-end synaptic complex during IS607-family transposition.

Chen, W.Mandali, S.Hancock, S.P.Kumar, P.Collazo, M.Cascio, D.Johnson, R.C.

(2018) Elife 7

  • DOI: https://doi.org/10.7554/eLife.39611
  • Primary Citation of Related Structures:
    6DGB, 6DGC

  • PubMed Abstract:

    IS 607 -family transposons are unusual because they do not have terminal inverted repeats or generate target site duplications. They encode two protein-coding genes, but only tnpA is required for transposition. Our X-ray structures confirm that TnpA is a member of the serine recombinase (SR) family, but the chemically-inactive quaternary structure of the dimer, along with the N-terminal location of the DNA binding domain, are different from other SRs. TnpA dimers from IS 1535 cooperatively associate with multiple subterminal repeats, which together with additional nonspecific binding, form a nucleoprotein filament on one transposon end that efficiently captures a second unbound end to generate the paired-end complex (PEC). Formation of the PEC does not require a change in the dimeric structure of the catalytic domain, but remodeling of the C-terminal α-helical region is involved. We posit that the PEC recruits a chemically-active conformer of TnpA to the transposon end to initiate DNA chemistry.


  • Organizational Affiliation

    Department of Biological Chemistry, David Geffen School of Medicine, University of California at Los Angeles, Los Angeles, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ISC1926 TnpA C-terminal catalytic domain
A, B, C, D
147Sulfolobus sp. L00 11Mutation(s): 0
UniProt
Find proteins for Q5MPE7 (Sulfolobus sp. L00 11)
Explore Q5MPE7
Go to UniProtKB:  Q5MPE7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5MPE7
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.92 Å
  • R-Value Free: 0.246
  • R-Value Work: 0.217
  • R-Value Observed: 0.220
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 97.08α = 90
b = 212.32β = 126.68
c = 61.6γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM038509

Revision History  (Full details and data files)

  • Version 1.0: 2018-07-18
    Type: Initial release
  • Version 1.1: 2019-04-03
    Changes: Data collection, Database references
  • Version 1.2: 2020-01-01
    Changes: Author supporting evidence
  • Version 1.3: 2023-10-11
    Changes: Data collection, Database references, Refinement description
