5XX7

Hetero-micro-seeding: Crystal structure of BPTI-[5,55]C14GA38I variant using micro-seeds from -C14GA38I variant


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.38 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.176
  • R-Value Observed: 0.178

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

A hetero-micro-seeding strategy for readily crystallizing closely related protein variants

Islam, M.M.Kuroda, Y.

(2017) Biochem Biophys Res Commun 493: 504-508

  • DOI: 10.1016/j.bbrc.2017.08.161
  • Primary Citation of Related Structures:
    5XX6, 5XX8, 5XX7

  • PubMed Abstract:
  • Protein crystallization remains difficult to rationalize and screening for optimal crystallization conditions is a tedious and time consuming procedure. Here, we report a hetero-micro-seeding strategy for producing high resolution crystals of closely related protein variants, where micro crystals from a readily crystallized variant are used as seeds to develop crystals of other variants less amenable to crystallization ...

    Protein crystallization remains difficult to rationalize and screening for optimal crystallization conditions is a tedious and time consuming procedure. Here, we report a hetero-micro-seeding strategy for producing high resolution crystals of closely related protein variants, where micro crystals from a readily crystallized variant are used as seeds to develop crystals of other variants less amenable to crystallization. We applied this strategy to Bovine Pancreatic Trypsin Inhibitor (BPTI) variants, which would not crystallize using standard crystallization practice. Out of six variants in our analysis, only one called BPTI-[5,55]A14G formed well behaving crystals; and the remaining five (A14GA38G, A14GA38V, A14GA38L, A14GA38I, and A14GA38K) could be crystallized only using micro-seeds from the BPTI-[5,55]A14G crystal. All hetero-seeded crystals diffracted at high resolution with minimum mosaicity, retaining the same space group and cell dimension. Moreover, hetero-micro-seeding did not introduce any biases into the mutant's structure toward the seed structure, as demonstrated by A14GA38I structures solved using micro-seeds from A14GA38G, A14GA38L and A14GA38I. Though hetero-micro-seeding is a simple and almost naïve strategy, this is the first direct demonstration of its workability. We believe that hetero-micro-seeding, which is contrasting with the popular idea that crystallization requires highly purified proteins, could contribute a new tool for rapidly solving protein structures in mutational analysis studies.


    Organizational Affiliation

    Department of Biotechnology and Life Sciences, Tokyo University of Agriculture and Technology, 2-24-16 Nakamachi, Koganei-shi, Tokyo 184-8588, Japan. Electronic address: ykuroda@cc.tuat.ac.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Pancreatic trypsin inhibitorA, B [auth D]58Bos taurusMutation(s): 5
UniProt
Find proteins for P00974 (Bos taurus)
Explore P00974
Go to UniProtKB:  P00974
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
SO4
Query on SO4

Download Ideal Coordinates CCD File
C [auth A], D [auth A], E [auth D]SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.38 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.176
  • R-Value Observed: 0.178
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 25.189α = 90
b = 41.306β = 99.35
c = 53.94γ = 90
Software Package:
Software NamePurpose
SHELXLdata collection
DENZOdata reduction
SCALAdata scaling
REFMACrefinement

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Deposited Date: 2017-07-01
  • Released Date: 2018-07-04
  • Deposition Author(s): Islam, M.M.

Revision History  (Full details and data files)

  • Version 1.0: 2018-07-04
    Type: Initial release
  • Version 1.1: 2019-01-16
    Changes: Data collection, Database references
