5XPP

Crystal structure of VDR-LBD complexed with 25RS-(Hydroxyphenyl)-2-methylidene-19,26,27-trinor-1,25-dihydroxyvitamin D3


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.210
  • R-Value Observed: 0.214

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Vitamin D Analogues with a p-Hydroxyphenyl Group at the C25 Position: Crystal Structure of Vitamin D Receptor Ligand-Binding Domain Complexed with the Ligand Explains the Mechanism Underlying Full Antagonistic Action

Kato, A.Yamao, M.Hashihara, Y.Ishida, H.Itoh, T.Yamamoto, K.

(2017) J Med Chem 60: 8394-8406

  • DOI: 10.1021/acs.jmedchem.7b00819
  • Primary Citation of Related Structures:
    5XPL, 5XPN, 5XPM, 5XPP, 5XPO

  • PubMed Abstract:
  • Vitamin D receptor (VDR) antagonists can be classified into two categories: the first category of VDR antagonists, which do not stabilize the helix 11-12, and the second category of antagonists, which destabilize the helix 6-7 region. To elucidate the mechanism underlying the first category antagonists by using the crystal structure, we designed and synthesized several VDR ligands with a p-hydroxyphenyl group at the C25-position ...

    Vitamin D receptor (VDR) antagonists can be classified into two categories: the first category of VDR antagonists, which do not stabilize the helix 11-12, and the second category of antagonists, which destabilize the helix 6-7 region. To elucidate the mechanism underlying the first category antagonists by using the crystal structure, we designed and synthesized several VDR ligands with a p-hydroxyphenyl group at the C25-position. Of these, 22S-butyl-25-carbonyl analogue 5b and 25-di-p-hydoroxyphenyl analogues 6a,b showed strong antagonistic activity. We succeeded in cocrystallizing the ligand-binding domain of VDR complexed with 5b and found that the structure showed an alternative conformation of the helix 11-12 that explained the mechanism of the first category antagonists. Taking the present and previous studies together, we could elucidate the mechanisms underlying first and second categories antagonists based on individual crystal structures. This study provides significant insights into antagonism against not only VDR but also nuclear receptors.


    Organizational Affiliation

    Laboratory of Drug Design and Medicinal Chemistry, Showa Pharmaceutical University , 3-3165 Higashi-Tamagawagakuen, Machida, Tokyo 194-8543, Japan.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Vitamin D3 receptorA271Rattus norvegicusMutation(s): 0
Gene Names: VdrNr1i1
UniProt
Find proteins for P13053 (Rattus norvegicus)
Explore P13053
Go to UniProtKB:  P13053
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Mediator of RNA polymerase II transcription subunit 1B [auth C]13Homo sapiensMutation(s): 0
Gene Names:
UniProt & NIH Common Fund Data Resources
Find proteins for Q15648 (Homo sapiens)
Explore Q15648
Go to UniProtKB:  Q15648
PHAROS:  Q15648
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
8BF (Subject of Investigation/LOI)
Query on 8BF

Download Ideal Coordinates CCD File
C [auth A](1~{R},3~{R})-5-[(2~{E})-2-[(1~{R},3~{a}~{S},7~{a}~{R})-1-[(2~{R},6~{R})-6-(4-hydroxyphenyl)-6-oxidanyl-hexan-2-yl]-7~{ a}-methyl-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-2-methylidene-cyclohexane-1,3-diol
C31 H44 O4
YBYKLULOUNBMJL-PJZOPEKWSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.85 Å
  • R-Value Free: 0.250
  • R-Value Work: 0.210
  • R-Value Observed: 0.214
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 154.38α = 90
b = 42.86β = 95.65
c = 41.74γ = 90
Software Package:
Software NamePurpose
REFMACrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-06-06
    Type: Initial release
  • Version 1.1: 2018-06-13
    Changes: Data collection, Database references
