5W5K

Crystal structure of Danio rerio histone deacetylase 6 catalytic domain 2 in complex with KV70


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.204
  • R-Value Observed: 0.208

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Synthesis and Biological Investigation of Phenothiazine-Based Benzhydroxamic Acids as Selective Histone Deacetylase 6 Inhibitors.

Vogerl, K.Ong, N.Senger, J.Herp, D.Schmidtkunz, K.Marek, M.Muller, M.Bartel, K.Shaik, T.B.Porter, N.J.Robaa, D.Christianson, D.W.Romier, C.Sippl, W.Jung, M.Bracher, F.

(2019) J Med Chem 62: 1138-1166

  • DOI: https://doi.org/10.1021/acs.jmedchem.8b01090
  • Primary Citation of Related Structures:
    5W5K

  • PubMed Abstract:

    The phenothiazine system was identified as a favorable cap group for potent and selective histone deacetylase 6 (HDAC6) inhibitors. Here, we report the preparation and systematic variation of phenothiazines and their analogues containing a benzhydroxamic acid moiety as the zinc-binding group. We evaluated their ability to selectively inhibit HDAC6 by a recombinant HDAC enzyme assay, by determining the protein acetylation levels in cells by western blotting (tubulin vs histone acetylation), and by assessing their effects on various cancer cell lines. Structure-activity relationship studies revealed that incorporation of a nitrogen atom into the phenothiazine framework results in increased potency and selectivity for HDAC6 (more than 500-fold selectivity relative to the inhibition of HDAC1, HDAC4, and HDAC8), as rationalized by molecular modeling and docking studies. The binding mode was confirmed by co-crystallization of the potent azaphenothiazine inhibitor with catalytic domain 2 from Danio rerio HDAC6.


  • Organizational Affiliation

    Department of Pharmacy-Center for Drug Research , Ludwig-Maximilians University Munich , Butenandtstr. 5-13 , 81377 Munich , Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Histone deacetylase 6
A, B, C
364Danio rerioMutation(s): 0
Gene Names: hdac6
UniProt
Find proteins for F8W4B7 (Danio rerio)
Explore F8W4B7
Go to UniProtKB:  F8W4B7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF8W4B7
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
K70 (Subject of Investigation/LOI)
Query on K70

Download Ideal Coordinates CCD File
G [auth A],
K [auth B],
O [auth C]
10-{[4-(hydroxycarbamoyl)phenyl]methyl}-5lambda~4~-pyrido[3,2-b][1,4]benzothiazin-10-ium
C19 H16 N3 O2 S
AIQWDXVAECMLSN-UHFFFAOYSA-O
ZN (Subject of Investigation/LOI)
Query on ZN

Download Ideal Coordinates CCD File
D [auth A],
H [auth B],
L [auth C]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
K
Query on K

Download Ideal Coordinates CCD File
E [auth A]
F [auth A]
I [auth B]
J [auth B]
M [auth C]
E [auth A],
F [auth A],
I [auth B],
J [auth B],
M [auth C],
N [auth C]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.220
  • R-Value Work: 0.204
  • R-Value Observed: 0.208
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 101.29α = 90
b = 170.94β = 90
c = 151.37γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
iMOSFLMdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-06-27
    Type: Initial release
  • Version 1.1: 2019-07-10
    Changes: Data collection, Database references
  • Version 1.2: 2023-10-04
    Changes: Advisory, Data collection, Database references, Derived calculations, Refinement description
