5V7W

Crystal structure of human PARP14 bound to 2-{[(1-methylpiperidin-4-yl)methyl]amino}-5,6,7,8-tetrahydro[1]benzothieno[2,3-d]pyrimidin-4(3H)-one inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.204

wwPDB Validation 3D Report Full Report


This is version 1.1 of the entry. See complete history

Literature

Identification of PARP14 inhibitors using novel methods for detecting auto-ribosylation.

Yoneyama-Hirozane, M.Matsumoto, S.I.Toyoda, Y.Saikatendu, K.S.Zama, Y.Yonemori, K.Oonishi, M.Ishii, T.Kawamoto, T.

(2017) Biochem. Biophys. Res. Commun. 486: 626-631

  • DOI: 10.1016/j.bbrc.2017.03.052
  • Primary Citation of Related Structures:

  • PubMed Abstract:
  • Poly(ADP-ribose) polymerases (PARPs) use nicotinamide adenine dinucleotide (NAD+) as a co-substrate to transfer ADP-ribose when it releases nicotinamide as the metabolized product. Enzymes of the PARP family play key roles in detecting and repairing ...

    Poly(ADP-ribose) polymerases (PARPs) use nicotinamide adenine dinucleotide (NAD+) as a co-substrate to transfer ADP-ribose when it releases nicotinamide as the metabolized product. Enzymes of the PARP family play key roles in detecting and repairing DNA, modifying chromatin, regulating transcription, controlling energy metabolism, and inducing cell death. PARP14, the original member of the PARP family, has been reported to be associated with the development of inflammatory diseases and various cancer types, making it a potential therapeutic target. In this study, we purified the macrodomain-containing PARP14 enzyme and established an assay for detecting the auto-ribosylation activity of PARP14 using RapidFire high-throughput mass spectrometry and immunoradiometric assay using [3H]NAD+. Subsequently, we performed high-throughput screening using the assays and identified small-molecule hit compounds, which showed NAD+-competitive and PARP14-selective inhibitory activities. Co-crystal structures of PARP14 with certain hit compounds revealed that the inhibitors bind to the NAD+-binding site. Finally, we confirmed that the hit compounds interacted with intracellular PARP14 by a cell-based protein stabilization assay. Thus, we successfully identified primary candidate compounds for further investigation.


    Organizational Affiliation

    Pharmaceutical Research Division, Takeda Pharmaceutical Company Limited, 26-1, Muraoka-Higashi 2-chome, Fujisawa, Kanagawa 251-8555, Japan. Electronic address: mariko.hirozane@takeda.com.




Macromolecules

Find similar proteins by: Sequence  |  Structure

Entity ID: 1
MoleculeChainsSequence LengthOrganismDetails
Poly [ADP-ribose] polymerase 14
A, B
194Homo sapiensMutation(s): 0
Gene Names: PARP14 (BAL2, KIAA1268)
EC: 2.4.2.-
Find proteins for Q460N5 (Homo sapiens)
Go to Gene View: PARP14
Go to UniProtKB:  Q460N5
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
91J
Query on 91J

Download SDF File
Download CCD File
A, B
2-{[(1-methylpiperidin-4-yl)methyl]amino}-5,6,7,8-tetrahydro[1]benzothieno[2,3-d]pyrimidin-4(3H)-one
C17 H24 N4 O S
JXQVQMRDGUVMOA-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.65 Å
  • R-Value Free: 0.266
  • R-Value Work: 0.204
  • Space Group: C 2 2 21
Unit Cell:
Length (Å)Angle (°)
a = 83.049α = 90.00
b = 144.907β = 90.00
c = 83.428γ = 90.00
Software Package:
Software NamePurpose
MOLREPphasing
HKL-2000data reduction
HKL-2000data scaling
REFMACrefinement

Structure Validation

View Full Validation Report or Ramachandran Plots



Entry History

Deposition Data

Revision History

  • Version 1.0: 2017-05-10
    Type: Initial release
  • Version 1.1: 2018-11-14
    Type: Data collection, Source and taxonomy
