Crystal Structure of the Marburg Virus VP35 Oligomerization Domain P4222

Experimental Data Snapshot

  • Resolution: 2.19 Å
  • R-Value Free: 0.342
  • R-Value Work: 0.312
  • R-Value Observed: 0.315

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

This is version 1.6 of the entry. See complete history


Crystal Structure of the Marburg Virus VP35 Oligomerization Domain.

Bruhn, J.F.Kirchdoerfer, R.N.Urata, S.M.Li, S.Tickle, I.J.Bricogne, G.Saphire, E.O.

(2017) J Virol 91

  • DOI: https://doi.org/10.1128/JVI.01085-16
  • Primary Citation of Related Structures:
    5TOH, 5TOI

  • PubMed Abstract:

    Marburg virus (MARV) is a highly pathogenic filovirus that is classified in a genus distinct from that of Ebola virus (EBOV) (genera Marburgvirus and Ebolavirus, respectively). Both viruses produce a multifunctional protein termed VP35, which acts as a polymerase cofactor, a viral protein chaperone, and an antagonist of the innate immune response. VP35 contains a central oligomerization domain with a predicted coiled-coil motif. This domain has been shown to be essential for RNA polymerase function. Here we present crystal structures of the MARV VP35 oligomerization domain. These structures and accompanying biophysical characterization suggest that MARV VP35 is a trimer. In contrast, EBOV VP35 is likely a tetramer in solution. Differences in the oligomeric state of this protein may explain mechanistic differences in replication and immune evasion observed for MARV and EBOV. Marburg virus can cause severe disease, with up to 90% human lethality. Its genome is concise, only producing seven proteins. One of the proteins, VP35, is essential for replication of the viral genome and for evasion of host immune responses. VP35 oligomerizes (self-assembles) in order to function, yet the structure by which it assembles has not been visualized. Here we present two crystal structures of this oligomerization domain. In both structures, three copies of VP35 twist about each other to form a coiled coil. This trimeric assembly is in contrast to tetrameric predictions for VP35 of Ebola virus and to known structures of homologous proteins in the measles, mumps, and Nipah viruses. Distinct oligomeric states of the Marburg and Ebola virus VP35 proteins may explain differences between them in polymerase function and immune evasion. These findings may provide a more accurate understanding of the mechanisms governing VP35's functions and inform the design of therapeutics.

  • Organizational Affiliation

    Department of Immunology and Microbial Science, The Scripps Research Institute, La Jolla, California, USA.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Polymerase cofactor VP35
A, B, C
72Marburg virus - Musoke, Kenya, 1980Mutation(s): 0
Gene Names: VP35
Find proteins for P35259 (Lake Victoria marburgvirus (strain Musoke-80))
Explore P35259
Go to UniProtKB:  P35259
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP35259
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.19 Å
  • R-Value Free: 0.342
  • R-Value Work: 0.312
  • R-Value Observed: 0.315
  • Space Group: P 42 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.49α = 90
b = 46.49β = 90
c = 310.93γ = 90
Software Package:
Software NamePurpose
PDB_EXTRACTdata extraction
Aimlessdata scaling
XDSdata reduction
STARANISOdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesT32 AI007606
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI118016
Burroughs Wellcome FundUnited States--
Department of Energy (DOE, United States)United StatesDE-AC02-76SF00515
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP41GM103393

Revision History  (Full details and data files)

  • Version 1.0: 2016-11-09
    Type: Initial release
  • Version 1.1: 2016-11-30
    Changes: Database references
  • Version 1.2: 2017-01-11
    Changes: Database references
  • Version 1.3: 2017-02-08
    Changes: Database references
  • Version 1.4: 2017-09-27
    Changes: Author supporting evidence, Refinement description
  • Version 1.5: 2019-12-04
    Changes: Author supporting evidence
  • Version 1.6: 2023-10-04
    Changes: Data collection, Database references, Refinement description
