5SLZ | pdb_00005slz

PanDDA analysis group deposition -- Crystal Structure of SARS-CoV-2 NSP14 in complex with Z2072621991

• PDB DOI: https://doi.org/10.2210/pdb5SLZ/pdb
• Deposition Group: G_1002230 (changed state) | Explore  G_1002230

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2022-03-03 Released: 2022-03-16
• Deposition Author(s): Imprachim, N., Yosaatmadja, Y., von-Delft, F., Bountra, C., Gileadi, O., Newman, J.A.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.54 Å
• R-Value Free:
  0.294 (Depositor), 0.282 (DCC)
• R-Value Work:
  0.222 (Depositor), 0.217 (DCC)
• R-Value Observed:
  0.226 (Depositor)

Starting Model: experimental

Literature

PanDDA analysis group deposition

Imprachim, N., Yosaatmadja, Y., von-Delft, F., Bountra, C., Gileadi, O., Newman, J.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 60.14 kDa
• Atom Count: 4,129
• Modeled Residue Count: 459
• Deposited Residue Count: 523
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Proofreading exoribonuclease nsp14	A [auth D]	523	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.1.13
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
LQP (Subject of Investigation/LOI)	G [auth D]	2-(difluoromethoxy)-1-[(3aR,6aS)-hexahydrocyclopenta[c]pyrrol-2(1H)-yl]ethan-1-one C10 H15 F2 N O2 GFKMUMPBDKROCT-OCAPTIKFSA-N
PO4	E [auth D], F [auth D]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
ZN	B [auth D], C [auth D], D	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.54 Å
• R-Value Free:  0.294 (Depositor), 0.282 (DCC)
• R-Value Work:  0.222 (Depositor), 0.217 (DCC)
• R-Value Observed: 0.226 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 67.7	α = 90
b = 67.76	β = 90
c = 138.54	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2022-03-16
Deposition Author(s): Imprachim, N., Yosaatmadja, Y., von-Delft, F., Bountra, C., Gileadi, O., Newman, J.A.

---

Funding Organization	Location	Grant Number
Not funded	United Kingdom	--

Revision History

• Version 1.0: 2022-03-16
  Type: Initial release

• Version 1.1: 2024-05-22
  Changes: Data collection
• Version 1.2: 2026-02-18
  Changes: Refinement description, Structure summary
