5SGL | pdb_00005sgl

CRYSTAL STRUCTURE OF HUMAN PHOSPHODIESTERASE 10 IN COMPLEX WITH c1(ccc(cc1)[C@H](OCC)C(=O)N\\N=C\\c2cc(c(Br)c(c2)OC)OC)n3nccc3, micromolar IC50=0.001626

PDB DOI: https://doi.org/10.2210/pdb5SGL/pdb
Deposition Group: G_1002229 | Explore G_1002229

Classification: HYDROLASE/HYDROLASE inhibitor
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-02-01 Released: 2022-10-12
Deposition Author(s): Joseph, C., Benz, J., Flohr, A., Groebke-Zbinden, K., Rudolph, M.G.
Funding Organization(s): F. Hoffmann-La Roche

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.28 Å
R-Value Free:
0.230 (Depositor), 0.230 (DCC)
R-Value Work:
0.181 (Depositor), 0.186 (DCC)
R-Value Observed:
0.183 (Depositor)

Starting Model: other
View more details

wwPDB Validation

Validation slider image for 5SGL

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Crystal Structure of a human phosphodiesterase 10 complex

Flohr, A., Schlatter, D., Kuhn, B., Rudolph, M.G.

To be published.

Macromolecule Content

Total Structure Weight: 159.96 kDa
Atom Count: 10,710
Modeled Residue Count: 1,255
Deposited Residue Count: 1,372
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
cAMP and cAMP-inhibited cGMP 3',5'-cyclic phosphodiesterase 10A	A, B, C, D	343	Homo sapiens	Mutation(s): 0 Gene Names: PDE10A EC: 3.1.4.17
UniProt & NIH Common Fund Data Resources
Find proteins for Q9Y233 (Homo sapiens) Explore Q9Y233 Go to UniProtKB: Q9Y233
PHAROS: Q9Y233 GTEx: ENSG00000112541
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9Y233
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IXT (Subject of Investigation/LOI) Query on IXT Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain J [auth B] SDF format, chain M [auth C] SDF format, chain P [auth D] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] MOL2 format, chain M [auth C] MOL2 format, chain P [auth D] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B] mmCIF format, chain M [auth C] mmCIF format, chain P [auth D]	G [auth A], J [auth B], M [auth C], P [auth D]	(2S)-N'-[(E)-(4-bromo-3,5-dimethoxyphenyl)methylidene]-2-ethoxy-2-[4-(1H-pyrazol-1-yl)phenyl]acetohydrazide C₂₂ H₂₃ Br N₄ O₄ BZLLDUWCQPWMTL-GQBLCDNYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D] Interactions & Density Focus chain G [auth A] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] SDF format, chain K [auth C] SDF format, chain N [auth D] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] MOL2 format, chain K [auth C] MOL2 format, chain N [auth D] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B] mmCIF format, chain K [auth C] mmCIF format, chain N [auth D]	E [auth A], H [auth B], K [auth C], N [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain K [auth C] Focus chain N [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain K [auth C] Focus chain N [auth D]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain L [auth C] SDF format, chain O [auth D] SDF format, chain I [auth B] SDF format, chain F [auth A] MOL2 format, chain L [auth C] MOL2 format, chain O [auth D] MOL2 format, chain I [auth B] MOL2 format, chain F [auth A] mmCIF format, chain L [auth C] mmCIF format, chain O [auth D] mmCIF format, chain I [auth B] mmCIF format, chain F [auth A]	F [auth A], I [auth B], L [auth C], O [auth D]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D] Interactions & Density Focus chain F [auth A] Focus chain I [auth B] Focus chain L [auth C] Focus chain O [auth D]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CME Query on CME	A, B, C, D	L-PEPTIDE LINKING	C₅ H₁₁ N O₃ S₂		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.28 Å
R-Value Free: 0.230 (Depositor), 0.230 (DCC)
R-Value Work: 0.181 (Depositor), 0.186 (DCC)
R-Value Observed: 0.183 (Depositor)

Space Group: H 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 135.574	α = 90
b = 135.574	β = 90
c = 235.517	γ = 120

Software Package:

Software Name	Purpose
XSCALE	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-10-12

Deposition Author(s):

Groebke-Zbinden, K.

Funding Organization	Location	Grant Number
F. Hoffmann-La Roche	Switzerland	--

Revision History (Full details and data files)

Version 1.0: 2022-10-12
Type: Initial release
Version 1.1: 2024-04-03
Changes: Data collection, Refinement description
Version 1.2: 2024-10-16
Changes: Structure summary
