5SAY | pdb_00005say

DDR1, N-[2-[3-(2-aminopyrimidin-5-yl)oxyphenyl]ethyl]-3-(trifluoromethoxy)benzamide, 2.190A, P1211, Rfree=27.7%

PDB DOI: https://doi.org/10.2210/pdb5SAY/pdb
Deposition Group: G_1002213 ExploreG_1002213

Classification: TRANSFERASE/TRANSFERASE INHIBITOR
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2021-06-22 Released: 2022-06-29
Deposition Author(s): Stihle, M., Richter, H., Benz, J., Hochstrasser, R., Rudolph, M.G.
Funding Organization(s): F. Hoffmann-La Roche

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free:
0.277 (Depositor), 0.280 (DCC)
R-Value Work:
0.202 (Depositor), 0.210 (DCC)
R-Value Observed:
0.206 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of a DDR1 complex

Richter, H., Prunotto, M., Kuhn, B., Rudolph, M.G.

To be published.

Macromolecule Content

Total Structure Weight: 75.75 kDa
Atom Count: 4,895
Modeled Residue Count: 578
Deposited Residue Count: 642
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Epithelial discoidin domain-containing receptor 1	A, B	321	Homo sapiens	Mutation(s): 0 Gene Names: DDR1, CAK, EDDR1, NEP, NTRK4, PTK3A, RTK6, TRKE EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q08345 (Homo sapiens) Explore Q08345 Go to UniProtKB: Q08345
PHAROS: Q08345 GTEx: ENSG00000204580
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q08345
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1IJ (Subject of Investigation/LOI) Query on 1IJ Download Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain S [auth B] MOL2 format, chain K [auth A] MOL2 format, chain S [auth B] mmCIF format, chain K [auth A] mmCIF format, chain S [auth B]	K [auth A], S [auth B]	N-(2-{3-[(2-aminopyrimidin-5-yl)oxy]phenyl}ethyl)-3-(trifluoromethoxy)benzamide C₂₀ H₁₇ F₃ N₄ O₃ JABJAPNNNDHTEK-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain S [auth B] Interactions & Density Focus chain K [auth A] Focus chain S [auth B]
IOD Query on IOD Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain J [auth A] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain R [auth B] SDF format, chain Q [auth B] SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain L [auth B] SDF format, chain I [auth A] SDF format, chain H [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain J [auth A] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain R [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain L [auth B] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain J [auth A] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain R [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain L [auth B] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], L [auth B], M [auth B], N [auth B], O [auth B], P [auth B], Q [auth B], R [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B]
