5PAI | pdb_00005pai

human factor VIIa in complex with N-(2-amino-1H-benzimidazol-5-yl)-1-[3-[[(3,5-dimethyl-1,2-oxazol-4-yl)carbamoylamino]methyl]phenyl]-5-hydroxypyrazole-4-carboxamide at 1.73A

PDB DOI: https://doi.org/10.2210/pdb5PAI/pdb
Deposition Group: G_1002015 ExploreG_1002015

Classification: HYDROLASE/HYDROLASE INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2016-11-10 Released: 2017-06-21
Deposition Author(s): Stihle, M., Mayweg, A., Roever, S., Rudolph, M.G.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.73 Å
R-Value Free:
0.181 (Depositor), 0.190 (DCC)
R-Value Work:
0.164 (Depositor), 0.180 (DCC)
R-Value Observed:
0.165 (Depositor)

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.4 of the entry. See complete history.

Literature

Crystal Structure of a Factor VIIa complex

Mayweg, A., Roever, S., Rudolph, M.G.

To be published.

Macromolecule Content

Total Structure Weight: 35.95 kDa
Atom Count: 2,819
Modeled Residue Count: 304
Deposited Residue Count: 318
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Coagulation factor VII light chain	A	64	Homo sapiens	Mutation(s): 0 Gene Names: F7 EC: 3.4.21.21
UniProt & NIH Common Fund Data Resources
Find proteins for P08709 (Homo sapiens) Explore P08709 Go to UniProtKB: P08709
PHAROS: P08709 GTEx: ENSG00000057593
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P08709
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Coagulation factor VII heavy chain	B	254	Homo sapiens	Mutation(s): 0 Gene Names: F7 EC: 3.4.21.21
UniProt & NIH Common Fund Data Resources
Find proteins for P08709 (Homo sapiens) Explore P08709 Go to UniProtKB: P08709
PHAROS: P08709 GTEx: ENSG00000057593
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P08709
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
7YM Query on 7YM Download Ideal Coordinates CCD File SDF format, chain H [auth B] MOL2 format, chain H [auth B] mmCIF format, chain H [auth B]	H [auth B]	N-(2-amino-1H-benzimidazol-5-yl)-1-[3-[[(3,5-dimethyl-1,2-oxazol-4-yl)carbamoylamino]methyl]phenyl]-5-hydroxypyrazole-4-carboxamide C₂₄ H₂₃ N₉ O₄ XUIGQXOFQZKKAN-UHFFFAOYSA-N		Interactions Focus chain H [auth B] Interactions & Density Focus chain H [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain F [auth B] SDF format, chain G [auth B] MOL2 format, chain F [auth B] MOL2 format, chain G [auth B] mmCIF format, chain F [auth B] mmCIF format, chain G [auth B]	F [auth B], G [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain F [auth B] Focus chain G [auth B] Interactions & Density Focus chain F [auth B] Focus chain G [auth B]
GOL Query on GOL Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain D [auth B] MOL2 format, chain D [auth B] mmCIF format, chain D [auth B]	D [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain D [auth B] Interactions & Density Focus chain D [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain E [auth B] MOL2 format, chain E [auth B] mmCIF format, chain E [auth B]	E [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth B] Interactions & Density Focus chain E [auth B]
