5OVP

PDZ domain from rat Shank3 bound to the C terminus of CIRL


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.193
  • R-Value Observed: 0.195

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural basis for PDZ domain interactions in the post-synaptic density scaffolding protein Shank3.

Ponna, S.K.Ruskamo, S.Myllykoski, M.Keller, C.Boeckers, T.M.Kursula, P.

(2018) J Neurochem 145: 449-463

  • DOI: 10.1111/jnc.14322
  • Primary Citation of Related Structures:
    5OVA, 5OVC, 5OVP, 5OVV, 6EXJ

  • PubMed Abstract:
  • The Shank proteins are crucial scaffolding elements of the post-synaptic density (PSD). One of the best-characterized domains in Shank is the PDZ domain, which binds to C-terminal segments of several other PSD proteins. We carried out a detailed structural analysis of Shank3 PDZ domain-peptide complexes, to understand determinants of binding affinity towards different ligand proteins ...

    The Shank proteins are crucial scaffolding elements of the post-synaptic density (PSD). One of the best-characterized domains in Shank is the PDZ domain, which binds to C-terminal segments of several other PSD proteins. We carried out a detailed structural analysis of Shank3 PDZ domain-peptide complexes, to understand determinants of binding affinity towards different ligand proteins. Ligand peptides from four different proteins were cocrystallized with the Shank3 PDZ domain, and binding affinities were determined calorimetrically. In addition to conserved class I interactions between the first and third C-terminal peptide residue and Shank3, side chain interactions of other residues in the peptide with the PDZ domain are important factors in defining affinity. Structural conservation suggests that the binding specificities of the PDZ domains from different Shanks are similar. Two conserved buried water molecules in PDZ domains may affect correct local folding of ligand recognition determinants. The solution structure of a tandem Shank3 construct containing the SH3 and PDZ domains showed that the two domains are close to each other, which could be of relevance, when recognizing and binding full target proteins. The SH3 domain did not affect the affinity of the PDZ domain towards short target peptides, and the schizophrenia-linked Shank3 mutation R536W in the linker between the domains had no effect on the structure or peptide interactions of the Shank3 SH3-PDZ unit. Our data show the spatial arrangement of two adjacent Shank domains and pinpoint affinity determinants for short PDZ domain ligands with limited sequence homology.


    Organizational Affiliation

    Department of Biomedicine, University of Bergen, Bergen, Norway.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
SH3 and multiple ankyrin repeat domains protein 3A96Rattus norvegicusMutation(s): 0
Gene Names: Shank3Prosap2
UniProt
Find proteins for Q9JLU4 (Rattus norvegicus)
Explore Q9JLU4
Go to UniProtKB:  Q9JLU4
Protein Feature View
Expand
  • Reference Sequence
  • Find similar proteins by:  Sequence   |   Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Adhesion G protein-coupled receptor L1B7Rattus norvegicusMutation(s): 1
Gene Names: Adgrl1CirlCirl1Cl1Lphn1
UniProt
Find proteins for O88917 (Rattus norvegicus)
Explore O88917
Go to UniProtKB:  O88917
Protein Feature View
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free: 0.235
  • R-Value Work: 0.193
  • R-Value Observed: 0.195
  • Space Group: P 32 1 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 32.09α = 90
b = 32.09β = 90
c = 150.22γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report




Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-03-07
    Type: Initial release
  • Version 1.1: 2018-07-11
    Changes: Data collection, Database references
