5NR4

Crystal structure of Clasp2 TOG1 domain


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.20 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.200
  • R-Value Observed: 0.201

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

CLASP Suppresses Microtubule Catastrophes through a Single TOG Domain.

Aher, A.Kok, M.Sharma, A.Rai, A.Olieric, N.Rodriguez-Garcia, R.Katrukha, E.A.Weinert, T.Olieric, V.Kapitein, L.C.Steinmetz, M.O.Dogterom, M.Akhmanova, A.

(2018) Dev Cell 46: 40-58.e8

  • DOI: https://doi.org/10.1016/j.devcel.2018.05.032
  • Primary Citation of Related Structures:
    5NR4

  • PubMed Abstract:

    The dynamic instability of microtubules plays a key role in controlling their organization and function, but the cellular mechanisms regulating this process are poorly understood. Here, we show that cytoplasmic linker-associated proteins (CLASPs) suppress transitions from microtubule growth to shortening, termed catastrophes, including those induced by microtubule-destabilizing agents and physical barriers. Mammalian CLASPs encompass three TOG-like domains, TOG1, TOG2, and TOG3, none of which bind to free tubulin. TOG2 is essential for catastrophe suppression, whereas TOG3 mildly enhances rescues but cannot suppress catastrophes. These functions are inhibited by the C-terminal domain of CLASP2, while the TOG1 domain can release this auto-inhibition. TOG2 fused to a positively charged microtubule-binding peptide autonomously accumulates at growing but not shrinking ends, suppresses catastrophes, and stimulates rescues. CLASPs suppress catastrophes by stabilizing growing microtubule ends, including incomplete ones, preventing their depolymerization and promoting their recovery into complete tubes. TOG2 domain is the key determinant of these activities.


  • Organizational Affiliation

    Cell Biology, Department of Biology, Faculty of Science, Utrecht University, Padualaan 8, 3584 CH Utrecht, the Netherlands.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
CLIP-associating protein 2
A, B
230Homo sapiensMutation(s): 0
Gene Names: CLASP2KIAA0627
UniProt & NIH Common Fund Data Resources
Find proteins for O75122 (Homo sapiens)
Explore O75122
Go to UniProtKB:  O75122
PHAROS:  O75122
GTEx:  ENSG00000163539
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO75122
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.20 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.200
  • R-Value Observed: 0.201
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.083α = 90
b = 47.116β = 115.83
c = 74.152γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
SHELXCDphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2018-05-30
    Type: Initial release
  • Version 1.1: 2018-07-04
    Changes: Data collection, Database references
  • Version 1.2: 2018-07-18
    Changes: Data collection, Database references
  • Version 1.3: 2019-10-16
    Changes: Data collection
