Cwp2 from Clostridium difficile

Experimental Data Snapshot

  • Resolution: 1.90 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.215
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report

This is version 1.5 of the entry. See complete history


Cwp2 from Clostridium difficile exhibits an extended three domain fold and cell adhesion in vitro.

Bradshaw, W.J.Kirby, J.M.Roberts, A.K.Shone, C.C.Acharya, K.R.

(2017) FEBS J 284: 2886-2898

  • DOI: https://doi.org/10.1111/febs.14157
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Colonization of the gut by Clostridium difficile requires the adhesion of the bacterium to host cells. A range of cell surface located factors have been linked to adhesion including the S-layer protein LMW SLP and the related protein Cwp66. As well as these proteins, the S-layer of C. difficile may contain many others. One such protein is Cwp2. Here, we demonstrate the production of a C. difficile strain 630 cwp2 knockout mutant and assess the effect on the bacterium. The mutant results in increased TcdA (toxin A) release and impaired cellular adherence in vitro. We also present the extended three domain structure of the 'functional' region of Cwp2, consisting of residues 29-318 at 1.9 Å, which is compared to that of LMW SLP and Cwp8. The adhesive properties of Cwp2 and LMW SLP, which are likely to be shared by Cwp8, are predicted to be mediated by the variable loop regions in domain 2.

  • Organizational Affiliation

    Department of Biology and Biochemistry, University of Bath, UK.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Cell surface protein (Putative S-layer protein)295Clostridioides difficile R20291Mutation(s): 0
Gene Names: CDR20291_2680
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on SO4

Download Ideal Coordinates CCD File
B [auth A]
C [auth A]
D [auth A]
E [auth A]
F [auth A]
B [auth A],
C [auth A],
D [auth A],
E [auth A],
F [auth A],
G [auth A],
H [auth A],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
R [auth A],
S [auth A],
T [auth A],
U [auth A]
O4 S
Experimental Data & Validation

Experimental Data

  • Resolution: 1.90 Å
  • R-Value Free: 0.245
  • R-Value Work: 0.215
  • R-Value Observed: 0.216
  • Space Group: P 63 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 134.828α = 90
b = 134.828β = 90
c = 102.835γ = 120
Software Package:
Software NamePurpose
DIALSdata reduction
Aimlessdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
Medical Research Council (United Kingdom)United KingdomMK/K027123/1

Revision History  (Full details and data files)

  • Version 1.0: 2017-07-05
    Type: Initial release
  • Version 1.1: 2017-07-19
    Changes: Database references
  • Version 1.2: 2017-09-13
    Changes: Author supporting evidence
  • Version 1.3: 2017-09-20
    Changes: Database references
  • Version 1.4: 2018-01-31
    Changes: Structure summary
  • Version 1.5: 2024-01-17
    Changes: Data collection, Database references, Refinement description
