Download MendeleyA crystallographic fragment study with cAMP-dependent protein kinase A
Siefker, C., Heine, A., Klebe, G.To be published.
5N32
cAMP-dependent Protein Kinase A from Cricetulus griseus in complex with fragment like molecule 4-chlorobenzyl carbamimidothioate
- PDB DOI: 10.2210/pdb5N32/pdb
- Classification: TRANSFERASE
- Organism(s): Cricetulus griseus
- Expression System: Escherichia coli BL21(DE3)
- Mutation(s): No
- Deposited: 2017-02-08 Released: 2018-02-28
Experimental Data Snapshot
- Method: X-RAY DIFFRACTION
- Resolution: 1.83 Å
- R-Value Free: 0.214
- R-Value Work: 0.188
- R-Value Observed: 0.189
This is version 1.1 of the entry. See complete history.
Literature
To be published.
Macromolecules
Find similar proteins by:
(by identity cutoff) | 3D Structure
Entity ID: 1 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| cAMP-dependent protein kinase catalytic subunit alpha | A | 353 | Cricetulus griseus | Mutation(s): 0 Gene Names: PRKACA EC: 2.7.11.11 |  |
UniProt | |||||
Find proteins for P25321 (Cricetulus griseus) Explore P25321 Go to UniProtKB: P25321 | |||||
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
| UniProt Group | P25321 | ||||
Protein Feature ViewExpand | |||||
| |||||
Find similar proteins by: Sequence | 3D Structure
Entity ID: 2 | |||||
|---|---|---|---|---|---|
| Molecule | Chains | Sequence Length | Organism | Details | Image |
| cAMP-dependent protein kinase inhibitor alpha-like protein | B | 19 | Cricetulus griseus | Mutation(s): 0 Gene Names: I79_011066 |  |
UniProt | |||||
Find proteins for G3HK48 (Cricetulus griseus) Explore G3HK48 Go to UniProtKB: G3HK48 | |||||
Entity Groups | |||||
| Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
| UniProt Group | G3HK48 | ||||
Protein Feature ViewExpand | |||||
| |||||
Small Molecules
| Ligands 2 Unique | |||||
|---|---|---|---|---|---|
| ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
| 8K5 Query on 8K5 | C [auth A], D [auth A] | [azanyl-[(4-chlorophenyl)methylsulfanyl]methylidene]azanium C8 H10 Cl N2 S YOCWIHYZDHPSHD-UHFFFAOYSA-O |  | Ligand Interaction | |
| MPD Query on MPD | E [auth A] | (4S)-2-METHYL-2,4-PENTANEDIOL C6 H14 O2 SVTBMSDMJJWYQN-YFKPBYRVSA-N |  | Ligand Interaction | |
| Modified Residues 2 Unique | |||||
|---|---|---|---|---|---|
| ID | Chains | Type | Formula | 2D Diagram | Parent |
| SEP Query on SEP | A | L-PEPTIDE LINKING | C3 H8 N O6 P |  | SER |
| TPO Query on TPO | A | L-PEPTIDE LINKING | C4 H10 N O6 P |  | THR |
Experimental Data & Validation
Experimental Data
- Method: X-RAY DIFFRACTION
- Resolution: 1.83 Å
- R-Value Free: 0.214
- R-Value Work: 0.188
- R-Value Observed: 0.189
- Space Group: P 21 21 21
Unit Cell:
| Length ( Å ) | Angle ( ˚ ) |
|---|---|
| a = 58.635 | α = 90 |
| b = 72.327 | β = 90 |
| c = 108.531 | γ = 90 |
| Software Name | Purpose |
|---|---|
| PHENIX | refinement |
| XDS | data reduction |
| XDS | data scaling |
| PHASER | phasing |
| Coot | model building |
Entry History
Deposition Data
- Released Date: 2018-02-28 Deposition Author(s): Siefker, C., Heine, A., Klebe, G.
Revision History (Full details and data files)
- Version 1.0: 2018-02-28
Type: Initial release - Version 1.1: 2019-08-14
Changes: Data collection
