Structure of PfIMP2 (Immune Mapped Protein 2 from Plasmodium falciparum) - an antigenic protein

Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Calculated: 20
  • Conformers Submitted: 15
  • Selection Criteria: structures with the lowest energy

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Toxoplasma gondii immune mapped protein 1 is anchored to the inner leaflet of the plasma membrane and adopts a novel protein fold.

Jia, Y.Benjamin, S.Liu, Q.Xu, Y.Dogga, S.K.Liu, J.Matthews, S.Soldati-Favre, D.

(2016) Biochim Biophys Acta 1865: 208-219

  • DOI: https://doi.org/10.1016/j.bbapap.2016.11.010
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    The immune mapped protein 1 (IMP1) was first identified as a protective antigen in Eimeria maxima and described as vaccine candidate and invasion factor in Toxoplasma gondii. We show here that TgIMP1 localizes to the inner leaflet of plasma membrane (PM) via dual acylation. Mutations either in the N-terminal myristoylation or palmitoylation sites (G2 and C5) cause relocalization of TgIMP1 to the cytosol. The first 11 amino acids are sufficient for PM targeting and the presence of lysine (K7) is critical. Disruption of TgIMP1 gene by double homologous recombination revealed no invasion defect or any measurable alteration in the lytic cycle of tachyzoites. Following immunization with TgIMP1 DNA vaccine, mice challenged with either wild type or IMP1-ko parasites showed no significant difference in protection. The sequence analysis identified a structured C-terminal domain that is present in a broader family of IMP1-like proteins conserved across the members of Apicomplexa. We present the solution structure of this domain determined from NMR data and describe a new protein fold not seen before.

  • Organizational Affiliation

    Department of Microbiology and Molecular Medicine, CMU, University of Geneva, Rue Michel-Servet 1, CH-1211 Geneva, Switzerland.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Uncharacterized protein156Plasmodium falciparum 3D7Mutation(s): 0
Gene Names: PF3D7_0730400
Find proteins for Q8IBF5 (Plasmodium falciparum (isolate 3D7))
Explore Q8IBF5
Go to UniProtKB:  Q8IBF5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8IBF5
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Calculated: 20
  • Conformers Submitted: 15
  • Selection Criteria: structures with the lowest energy

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-12-07
    Type: Initial release
  • Version 1.1: 2016-12-14
    Changes: Database references
  • Version 1.2: 2019-05-08
    Changes: Data collection
  • Version 1.3: 2024-05-15
    Changes: Data collection, Database references
