5KWE | pdb_00005kwe

Thermostable mutant of halohydrin dehalogenase HheC - C153N


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:
    0.166 (Depositor), 0.166 (DCC)
  • R-Value Work:
    0.138 (Depositor), 0.138 (DCC)
  • R-Value Observed:
    0.140 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5KWE

This is version 1.2 of the entry. See complete history

Literature

A robust cosolvent-compatible halohydrin dehalogenase by computational library design.

Arabnejad, H.Dal Lago, M.Jekel, P.A.Floor, R.J.Thunnissen, A.W.H.Terwisscha van Scheltinga, A.C.Wijma, H.J.Janssen, D.B.

(2017) Protein Eng Des Sel 30: 173-187

  • DOI: https://doi.org/10.1093/protein/gzw068
  • Primary Citation Related Structures:
    5KVC, 5KWE

  • PubMed Abstract:

    To improve the applicability of halohydrin dehalogenase as a catalyst for reactions in the presence of organic cosolvents, we explored a computational library design strategy (Framework for Rapid Enzyme Stabilization by Computational libraries) that involves discovery and in silico evaluation of stabilizing mutations. Energy calculations, disulfide bond predictions and molecular dynamics simulations identified 218 point mutations and 35 disulfide bonds with predicted stabilizing effects. Experiments confirmed 29 stabilizing point mutations, most of which were located in two distinct regions, whereas introduction of disulfide bonds was not effective. Combining the best mutations resulted in a 12-fold mutant (HheC-H12) with a 28°C higher apparent melting temperature and a remarkable increase in resistance to cosolvents. This variant also showed a higher optimum temperature for catalysis while activity at low temperature was preserved. Mutant H12 was used as a template for the introduction of mutations that enhance enantioselectivity or activity. Crystal structures showed that the structural changes in the H12 mutant mostly agreed with the computational predictions and that the enhanced stability was mainly due to mutations that redistributed surface charges and improved interactions between subunits, the latter including better interactions of water molecules at the subunit interfaces.


  • Organizational Affiliation
    • Biotransformation and Biocatalysis, Groningen Biomolecular Science and Biotechnology Institute, University of Groningen, Nijenborgh 4, 9747 AG Groningen, The Netherlands.

Macromolecule Content

  • Total Structure Weight: 119.63 kDa
  • Atom Count: 9,346
  • Modeled Residue Count: 1,019
  • Deposited Residue Count: 1,084
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Halohydrin dehalogenase
A, B, C, D
271Agrobacterium tumefaciensMutation(s): 1
Gene Names: hheC
UniProt
Find proteins for Q93D82 (Agrobacterium tumefaciens)
Explore Q93D82
Go to UniProtKB:  Q93D82
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ93D82
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CL

Query on CL



Download:Ideal Coordinates CCD File
E [auth A],
G [auth B],
I [auth B],
J [auth C],
L [auth D]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA

Query on NA



Download:Ideal Coordinates CCD File
F [auth A],
H [auth B],
K [auth C],
M [auth D]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free:  0.166 (Depositor), 0.166 (DCC)
  • R-Value Work:  0.138 (Depositor), 0.138 (DCC)
  • R-Value Observed: 0.140 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.744α = 90
b = 70.126β = 100.72
c = 118.342γ = 90
Software Package:
Software NamePurpose
Aimlessdata scaling
PHASERphasing
PHENIXrefinement
PDB_EXTRACTdata extraction
XDSdata reduction

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-01-11
    Type: Initial release
  • Version 1.1: 2017-05-03
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Derived calculations, Refinement description
