Structure of the apo PCP-E didomain of the gramicidin S synthetase A

Experimental Data Snapshot

  • Resolution: 1.75 Å
  • R-Value Free: 0.201
  • R-Value Work: 0.169
  • R-Value Observed: 0.170

wwPDB Validation   3D Report Full Report

This is version 1.3 of the entry. See complete history


Interdomain and Intermodule Organization in Epimerization Domain Containing Nonribosomal Peptide Synthetases.

Chen, W.H.Li, K.Guntaka, N.S.Bruner, S.D.

(2016) ACS Chem Biol 11: 2293-2303

  • DOI: https://doi.org/10.1021/acschembio.6b00332
  • Primary Citation of Related Structures:
    5ISW, 5ISX

  • PubMed Abstract:

    Nonribosomal peptide synthetases are large, complex multidomain enzymes responsible for the biosynthesis of a wide range of peptidic natural products. Inherent to synthetase chemistry is the thioester templated mechanism that relies on protein/protein interactions and interdomain dynamics. Several questions related to structure and mechanism remain to be addressed, including the incorporation of accessory domains and intermodule interactions. The inclusion of nonproteinogenic d-amino acids into peptide frameworks is a common and important modification for bioactive nonribosomal peptides. Epimerization domains, embedded in nonribosomal peptide synthetases assembly lines, catalyze the l- to d-amino acid conversion. Here we report the structure of the epimerization domain/peptidyl carrier protein didomain construct from the first module of the cyclic peptide antibiotic gramicidin synthetase. Both holo (phosphopantethiene post-translationally modified) and apo structures were determined, each representing catalytically relevant conformations of the two domains. The structures provide insight into domain-domain recognition, substrate delivery during the assembly line process, in addition to the structural organization of homologous condensation domains, canonical players in all synthetase modules.

  • Organizational Affiliation

    Department of Chemistry, University of Florida , P.O. Box 117200, Gainesville, Florida 32611, United States.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Gramicidin S synthase 1573Brevibacillus brevisMutation(s): 0
Gene Names: grsAgrs1
Find proteins for P0C062 (Brevibacillus brevis)
Explore P0C062
Go to UniProtKB:  P0C062
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C062
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on GOL

Download Ideal Coordinates CCD File
C3 H8 O3
Experimental Data & Validation

Experimental Data

  • Resolution: 1.75 Å
  • R-Value Free: 0.201
  • R-Value Work: 0.169
  • R-Value Observed: 0.170
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 53.77α = 65.72
b = 57.637β = 65.47
c = 61.384γ = 84.88
Software Package:
Software NamePurpose
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Science Foundation (NSF, United States)United States1411991

Revision History  (Full details and data files)

  • Version 1.0: 2016-06-29
    Type: Initial release
  • Version 1.1: 2016-08-31
    Changes: Database references
  • Version 1.2: 2017-09-20
    Changes: Author supporting evidence, Derived calculations
  • Version 1.3: 2019-11-27
    Changes: Author supporting evidence
