Crystal structure of Dmd from phage RB69

Experimental Data Snapshot

  • Resolution: 1.75 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.192
  • R-Value Observed: 0.193

wwPDB Validation   3D Report Full Report

This is version 1.1 of the entry. See complete history


Structural characterizations of phage antitoxin Dmd and its interactions with bacterial toxin RnlA

Wei, Y.Gao, Z.Q.Zhang, H.Dong, Y.H.

(2016) Biochem Biophys Res Commun 472: 592-597

  • DOI: https://doi.org/10.1016/j.bbrc.2016.03.025
  • Primary Citation of Related Structures:

  • PubMed Abstract:

    Toxin-antitoxin (TA) loci are widespread in bacteria plasmids and chromosomes, and target various cellular functions to regulate cell growth and death. A type II TA system RnlA-RnlB from Escherichia coli is associated with phage-resistance. After the infection of bacteriophage T4 with Dmd defection, RnlA is activated by the disappearance of RnlB, resulting in the rapid degradation of T4 mRNAs. Dmd can bind to RnlA directly and neutralize RnlA toxicity to allow phage reproduction. Dmd represent a heterogenous antitoxin of RnlA replacing antitoxin RnlB. Here, we reported two structures of Dmd from T4 phage and RB69 phage. Both Dmd structures are high similar with a compacted domain composed of a four-stranded anti-parallel β-sheet and an α-helix. Chromatography and SAXS suggest Dmd forms a dimer in solution consistent with that in crystal. Structure-based mutagenesis of Dmd reveals key residues involved in RnlA-binding. Possibility cavities in Dmd used for compounds design were modeled. Our structural study revealed the recognition and inhibition mechanism of RnlA by Dmd and providing a potential laboratory phage prevention target for drug design.

  • Organizational Affiliation

    Beijing Synchrotron Radiation Facility, Institute of High Energy Physics, Chinese Academy of Sciences, Beijing, 100049, China.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Dmd discriminator of mRNA degradation
A, B
64Escherichia phage RB69Mutation(s): 0
Gene Names: dmd
Find proteins for Q7Y599 (Escherichia phage RB69)
Explore Q7Y599
Go to UniProtKB:  Q7Y599
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ7Y599
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 1.75 Å
  • R-Value Free: 0.223
  • R-Value Work: 0.192
  • R-Value Observed: 0.193
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 31.91α = 90
b = 53.933β = 90
c = 75.454γ = 90
Software Package:
Software NamePurpose
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-02-15
    Type: Initial release
  • Version 1.1: 2023-11-08
    Changes: Data collection, Database references, Refinement description
