5I6V

Structure of F285S, a Cancer-Associated Mutation of the Oncogenic Phosphatase SHP2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.87 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.201
  • R-Value Observed: 0.203

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural and Functional Consequences of Three Cancer-Associated Mutations of the Oncogenic Phosphatase SHP2.

LaRochelle, J.R.Fodor, M.Xu, X.Durzynska, I.Fan, L.Stams, T.Chan, H.M.LaMarche, M.J.Chopra, R.Wang, P.Fortin, P.D.Acker, M.G.Blacklow, S.C.

(2016) Biochemistry 55: 2269-2277

  • DOI: 10.1021/acs.biochem.5b01287
  • Primary Citation of Related Structures:
    5I6V, 5IBM, 5IBS

  • PubMed Abstract:
  • The proto-oncogene PTPN11 encodes a cytoplasmic protein tyrosine phosphatase, SHP2, which is required for normal development and sustained activation of the Ras-MAPK signaling pathway. Germline mutations in SHP2 cause developmental disorders, and som ...

    The proto-oncogene PTPN11 encodes a cytoplasmic protein tyrosine phosphatase, SHP2, which is required for normal development and sustained activation of the Ras-MAPK signaling pathway. Germline mutations in SHP2 cause developmental disorders, and somatic mutations have been identified in childhood and adult cancers and drive leukemia in mice. Despite our knowledge of the PTPN11 variations associated with pathology, the structural and functional consequences of many disease-associated mutants remain poorly understood. Here, we combine X-ray crystallography, small-angle X-ray scattering, and biochemistry to elucidate structural and mechanistic features of three cancer-associated SHP2 variants harboring single point mutations within the N-SH2:PTP interdomain autoinhibitory interface. Our findings directly compare the impact of each mutation on autoinhibition of the phosphatase and advance the development of structure-guided and mutation-specific SHP2 therapies.


    Organizational Affiliation

    Department of Cancer Biology, Dana-Farber Cancer Institute , Boston, Massachusetts 02215, United States.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Tyrosine-protein phosphatase non-receptor type 11AB525Homo sapiensMutation(s): 1
Gene Names: PTPN11PTP2CSHPTP2
EC: 3.1.3.48
Find proteins for Q06124 (Homo sapiens)
Explore Q06124
Go to UniProtKB:  Q06124
NIH Common Fund Data Resources
PHAROS  Q06124
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download CCD File
B
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.87 Å
  • R-Value Free: 0.232
  • R-Value Work: 0.201
  • R-Value Observed: 0.203
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 45.822α = 90
b = 214.263β = 96.08
c = 55.472γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Deposited Date: 2016-02-16
  • Released Date: 2016-04-13
  • Deposition Author(s): Xu, X., Blacklow, S.C.

Funding OrganizationLocationGrant Number
William Lawrence Blanche Hughes FoundationUnited StatesJCA, SCB, KS

Revision History

  • Version 1.0: 2016-04-13
    Type: Initial release
  • Version 1.1: 2016-05-04
    Changes: Database references
