5H01 | pdb_00005h01

The crystal structure of D-2-halacid dehalogenase mutant

PDB DOI: https://doi.org/10.2210/pdb5H01/pdb

Classification: HYDROLASE
Organism(s): Pseudomonas putida
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2016-10-02 Released: 2017-10-04
Deposition Author(s): Xue, S., Wang, Y.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free:
0.312 (Depositor), 0.300 (DCC)
R-Value Work:
0.253 (Depositor), 0.250 (DCC)
R-Value Observed:
0.256 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

The crystal structure of D-2-halacid dehalogenase mutant

Xue, S., Wang, Y.

To be published.

Macromolecule Content

Total Structure Weight: 140.34 kDa
Atom Count: 9,743
Modeled Residue Count: 1,168
Deposited Residue Count: 1,236
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
(R)-2-haloacid dehalogenase	A, B, C, D	309	Pseudomonas putida	Mutation(s): 1 Gene Names: hadD EC: 3.8.1.9
UniProt
Find proteins for Q52086 (Pseudomonas putida) Explore Q52086 Go to UniProtKB: Q52086
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q52086
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.19 Å
R-Value Free: 0.312 (Depositor), 0.300 (DCC)
R-Value Work: 0.253 (Depositor), 0.250 (DCC)
R-Value Observed: 0.256 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 89.713	α = 90
b = 97.181	β = 107.53
c = 93.75	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data scaling
PHENIX	model building
Coot	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2017-10-04

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2017-10-04
Type: Initial release
Version 1.1: 2023-11-08
Changes: Data collection, Database references, Refinement description
