Crystal structure of Uracil DNA glycosylase -Xanthine complex from Bradyrhizobium diazoefficiens

Experimental Data Snapshot

  • Resolution: 2.80 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.220
  • R-Value Observed: 0.221

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history


Uracil DNA glycosylase (UDG) activities in Bradyrhizobium diazoefficiens: characterization of a new class of UDG with broad substrate specificity

Chembazhi, U.V.Patil, V.V.Sah, S.Reeve, W.Tiwari, R.P.Woo, E.Varshney, U.

(2017) Nucleic Acids Res 45: 5863-5876

  • DOI: https://doi.org/10.1093/nar/gkx209
  • Primary Citation of Related Structures:
    5GN2, 5GN3, 5GNW, 5GRK

  • PubMed Abstract:

    Repair of uracils in DNA is initiated by uracil DNA glycosylases (UDGs). Family 1 UDGs (Ung) are the most efficient and ubiquitous proteins having an exquisite specificity for uracils in DNA. Ung are characterized by motifs A (GQDPY) and B (HPSPLS) sequences. We report a novel dimeric UDG, Blr0248 (BdiUng) from Bradyrhizobium diazoefficiens. Although BdiUng contains the motif A (GQDPA), it has low sequence identity to known UDGs. BdiUng prefers single stranded DNA and excises uracil, 5-hydroxymethyl-uracil or xanthine from it. BdiUng is impervious to inhibition by AP DNA, and Ugi protein that specifically inhibits family 1 UDGs. Crystal structure of BdiUng shows similarity with the family 4 UDGs in its overall fold but with family 1 UDGs in key active site residues. However, instead of a classical motif B, BdiUng has a uniquely extended protrusion explaining the lack of Ugi inhibition. Structural and mutational analyses of BdiUng have revealed the basis for the accommodation of diverse substrates into its substrate binding pocket. Phylogenetically, BdiUng belongs to a new UDG family. Bradyrhizobium diazoefficiens presents a unique scenario where the presence of at least four families of UDGs may compensate for the absence of an efficient family 1 homologue.

  • Organizational Affiliation

    Department of Microbiology and Cell Biology, Indian Institute of Science, Bangalore 560012, India.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Blr0248 protein
A, B, C, D
272Bradyrhizobium diazoefficiens USDA 110Mutation(s): 0
Gene Names: blr0248
Find proteins for Q89XR0 (Bradyrhizobium diazoefficiens (strain JCM 10833 / BCRC 13528 / IAM 13628 / NBRC 14792 / USDA 110))
Explore Q89XR0
Go to UniProtKB:  Q89XR0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ89XR0
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.80 Å
  • R-Value Free: 0.244
  • R-Value Work: 0.220
  • R-Value Observed: 0.221
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.023α = 90
b = 89.894β = 90
c = 255.339γ = 90
Software Package:
Software NamePurpose

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-05-03
    Type: Initial release
  • Version 1.1: 2017-06-14
    Changes: Database references
