5GQV

Crystal structure of branching enzyme from Cyanothece sp. ATCC 51142 in complex with maltohexaose


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.163
  • R-Value Observed: 0.166

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history


Literature

Bound Substrate in the Structure of Cyanobacterial Branching Enzyme Supports a New Mechanistic Model

Hayashi, M.Suzuki, R.Colleoni, C.Ball, S.G.Fujita, N.Suzuki, E.

(2017) J Biol Chem 292: 5465-5475

  • DOI: 10.1074/jbc.M116.755629
  • Primary Citation of Related Structures:
    5GQU, 5GQV, 5GQW, 5GQX

  • PubMed Abstract:
  • Branching enzyme (BE) catalyzes the formation of α-1,6-glucosidic linkages in amylopectin and glycogen. The reaction products are variable, depending on the organism sources, and the mechanistic basis for these different outcomes is unclear. Although most cyanobacteria have only one BE isoform belonging to glycoside hydrolase family 13, Cyanothece sp ...

    Branching enzyme (BE) catalyzes the formation of α-1,6-glucosidic linkages in amylopectin and glycogen. The reaction products are variable, depending on the organism sources, and the mechanistic basis for these different outcomes is unclear. Although most cyanobacteria have only one BE isoform belonging to glycoside hydrolase family 13, Cyanothece sp. ATCC 51142 has three isoforms (BE1, BE2, and BE3) with distinct enzymatic properties, suggesting that investigations of these enzymes might provide unique insights into this system. Here, we report the crystal structure of ligand-free wild-type BE1 (residues 5-759 of 1-773) at 1.85 Å resolution. The enzyme consists of four domains, including domain N, carbohydrate-binding module family 48 (CBM48), domain A containing the catalytic site, and domain C. The central domain A displays a (β/α) 8 -barrel fold, whereas the other domains adopt β-sandwich folds. Domain N was found in a new location at the back of the protein, forming hydrogen bonds and hydrophobic interactions with CBM48 and domain A. Site-directed mutational analysis identified a mutant (W610N) that bound maltoheptaose with sufficient affinity to enable structure determination at 2.30 Å resolution. In this structure, maltoheptaose was bound in the active site cleft, allowing us to assign subsites -7 to -1. Moreover, seven oligosaccharide-binding sites were identified on the protein surface, and we postulated that two of these in domain A served as the entrance and exit of the donor/acceptor glucan chains, respectively. Based on these structures, we propose a substrate binding model explaining the mechanism of glycosylation/deglycosylation reactions catalyzed by BE.


    Related Citations:
    • Crystallization and crystallographic analysis of branching enzymes from Cyanothece sp. ATCC 51142
      Hayashi, M., Suzuki, R., Colleoni, C., Ball, S.G., Fujita, N., Suzuki, E.
      (2015) Acta Crystallogr F Struct Biol Commun 71: 1109

    Organizational Affiliation

    From the Department of Biological Production, Faculty of Bioresource Sciences, Akita Prefectural University, Shimoshinjyo-Nakano, Akita 010-0195, Japan and esuzuki@akita-pu.ac.jp.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
1,4-alpha-glucan branching enzyme GlgBA793Crocosphaera subtropica ATCC 51142Mutation(s): 0
Gene Names: glgBglgB1cce_2248
EC: 2.4.1.18
UniProt
Find proteins for B1WPM8 (Crocosphaera subtropica (strain ATCC 51142 / BH68))
Explore B1WPM8
Go to UniProtKB:  B1WPM8
Protein Feature View
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseB, G6N/A Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G91368RN
GlyCosmos:  G91368RN
GlyGen:  G91368RN
Entity ID: 3
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseC, F, H4N/A Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G87171PZ
GlyCosmos:  G87171PZ
GlyGen:  G87171PZ
Entity ID: 4
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseD, I3N/A Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G96370VA
GlyCosmos:  G96370VA
GlyGen:  G96370VA
Entity ID: 5
MoleculeChainsChain Length2D DiagramGlycosylation3D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranoseE7N/A Oligosaccharides Interaction
Glycosylation Resources
GlyTouCan:  G41288IQ
GlyCosmos:  G41288IQ
GlyGen:  G41288IQ
Small Molecules
Ligands 2 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
GOL
Query on GOL

Download Ideal Coordinates CCD File
J [auth A], K [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
 Ligand Interaction
MG
Query on MG

Download Ideal Coordinates CCD File
L [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
 Ligand Interaction
Biologically Interesting Molecules (External Reference) 3 Unique
Entity ID: 2
IDChainsNameType/Class2D Diagram3D Interactions
PRD_900035
Query on PRD_900035
B, Galpha-maltohexaoseOligosaccharide / Substrate analog Ligand Interaction
Entity ID: 3
IDChainsNameType/Class2D Diagram3D Interactions
PRD_900010
Query on PRD_900010
C, F, Halpha-maltotetraoseOligosaccharide / Substrate analog Ligand Interaction
Entity ID: 4
IDChainsNameType/Class2D Diagram3D Interactions
PRD_900009
Query on PRD_900009
D, Ialpha-maltotrioseOligosaccharide / Nutrient Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free: 0.224
  • R-Value Work: 0.163
  • R-Value Observed: 0.166
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 134.126α = 90
b = 134.126β = 90
c = 184.325γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report




Entry History & Funding Information

Deposition Data

  • Deposited Date: 2016-08-08
  • Released Date: 2017-02-22
  • Deposition Author(s): Suzuki, R., Suzuki, E.

Funding OrganizationLocationGrant Number
Shimadzu Science FoundationJapan120003
JSPS KAKENHIJapan15K18685
JSPS KAKENHIJapan25440193

Revision History  (Full details and data files)

  • Version 1.0: 2017-02-22
    Type: Initial release
  • Version 1.1: 2017-04-12
    Changes: Database references
  • Version 1.2: 2020-02-26
    Changes: Data collection
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Structure summary
