5FIL | pdb_00005fil

Bovine mitochondrial ATP synthase state 3b


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5FIL

This is version 1.3 of the entry. See complete history

Literature

Structure and conformational states of the bovine mitochondrial ATP synthase by cryo-EM.

Zhou, A.Rohou, A.Schep, D.G.Bason, J.V.Montgomery, M.G.Walker, J.E.Grigorieff, N.Rubinstein, J.L.

(2015) Elife 4: e10180-e10180

  • DOI: https://doi.org/10.7554/eLife.10180
  • Primary Citation Related Structures:
    5ARA, 5ARE, 5ARH, 5ARI, 5FIJ, 5FIK, 5FIL

  • PubMed Abstract:

    Adenosine triphosphate (ATP), the chemical energy currency of biology, is synthesized in eukaryotic cells primarily by the mitochondrial ATP synthase. ATP synthases operate by a rotary catalytic mechanism where proton translocation through the membrane-inserted FO region is coupled to ATP synthesis in the catalytic F1 region via rotation of a central rotor subcomplex. We report here single particle electron cryomicroscopy (cryo-EM) analysis of the bovine mitochondrial ATP synthase. Combining cryo-EM data with bioinformatic analysis allowed us to determine the fold of the a subunit, suggesting a proton translocation path through the FO region that involves both the a and b subunits. 3D classification of images revealed seven distinct states of the enzyme that show different modes of bending and twisting in the intact ATP synthase. Rotational fluctuations of the c8-ring within the FO region support a Brownian ratchet mechanism for proton-translocation-driven rotation in ATP synthases.


  • Organizational Affiliation
    • The Hospital for Sick Children Research Institute, Toronto, Canada.

Macromolecule Content

  • Total Structure Weight: 518.89 kDa
  • Atom Count: 18,546
  • Modeled Residue Count: 4,641
  • Deposited Residue Count: 4,803
  • Unique protein chains: 11

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT ALPHA, MITOCHONDRIAL
A, B, C
510Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P19483 (Bos taurus)
Explore P19483
Go to UniProtKB:  P19483
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP19483
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT BETA, MITOCHONDRIAL
D, E, F
482Bos taurusMutation(s): 0
EC: 3.6.3.14 (PDB Primary Data), 7.1.2.2 (UniProt)
Membrane Entity: Yes
UniProt
Find proteins for P00829 (Bos taurus)
Explore P00829
Go to UniProtKB:  P00829
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00829
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT GAMMA, MITOCHONDRIAL273Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P05631 (Bos taurus)
Explore P05631
Go to UniProtKB:  P05631
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05631
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT DELTA, MITOCHONDRIAL146Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P05630 (Bos taurus)
Explore P05630
Go to UniProtKB:  P05630
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05630
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 5
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT EPSILON, MITOCHONDRIAL50Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P05632 (Bos taurus)
Explore P05632
Go to UniProtKB:  P05632
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP05632
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 6
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE F(0) COMPLEX SUBUNIT C1, MITOCHONDRIAL
J, K, L, M, N
J, K, L, M, N, O, P, Q
72Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P32876 (Bos taurus)
Explore P32876
Go to UniProtKB:  P32876
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32876
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 7
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT O, MITOCHONDRIALR [auth S]190Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P13621 (Bos taurus)
Explore P13621
Go to UniProtKB:  P13621
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13621
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 8
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE F(0) COMPLEX SUBUNIT B1, MITOCHONDRIALS [auth T]174Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P13619 (Bos taurus)
Explore P13619
Go to UniProtKB:  P13619
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13619
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 9
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT D, MITOCHONDRIALT [auth U]124Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P13620 (Bos taurus)
Explore P13620
Go to UniProtKB:  P13620
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP13620
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 10
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE-COUPLING FACTOR 6, MITOCHONDRIALU [auth V]77Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P02721 (Bos taurus)
Explore P02721
Go to UniProtKB:  P02721
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02721
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 11
MoleculeChains  Sequence LengthOrganismDetailsImage
ATP SYNTHASE SUBUNIT BETA, MITOCHONDRIALV [auth W]217Bos taurusMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P00847 (Bos taurus)
Explore P00847
Go to UniProtKB:  P00847
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00847
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 7.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONFREALIGN
RECONSTRUCTIONRELION

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-10-14
    Type: Initial release
  • Version 1.1: 2016-12-21
    Changes: Database references
  • Version 1.2: 2017-08-02
    Changes: Data collection
  • Version 1.3: 2024-05-08
    Changes: Data collection, Database references, Derived calculations, Refinement description
