Biological Assembly 1

 3D View: Structure | 1D-3D View | Electron Density | Validation Report

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 43.00 kDa
• Atom Count: 3040
• Modelled Residue Count: 346
• Deposited Residue Count: 375
• Unique protein chains: 2

5ETF

Structure of dead kinase MAPK14 with bound the KIM domain of MKK6

• PDB DOI: 10.2210/pdb5ETF/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2015-11-17 Released: 2016-10-26
• Deposition Author(s): Pellegrini, E., Palencia, A., Braun, L., Kapp, U., Bougdour, A., Belrhali, H., Bowler, M.W., Hakimi, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free: 0.231
• R-Value Work: 0.163
• R-Value Observed: 0.166

Literature

Structural Basis for the Subversion of MAP Kinase Signaling by an Intrinsically Disordered Parasite Secreted Agonist.

Pellegrini, E., Palencia, A., Braun, L., Kapp, U., Bougdour, A., Belrhali, H., Bowler, M.W., Hakimi, M.A.

(2017) Structure 25: 16-26

• PubMed: 27889209
• DOI: 10.1016/j.str.2016.10.011
• Primary Citation of Related Structures:
  5ETA, 5ETF


• PubMed Abstract:


The causative agent of toxoplasmosis, the intracellular parasite Toxoplasma gondii, delivers a protein, GRA24, into the cells it infects that interacts with the mitogen-activated protein (MAP) kinase p38α (MAPK14), leading to activation and nuclear translocation of the host kinase and a subsequent inflammatory response that controls the progress of the parasite. The purification of a recombinant complex of GRA24 and human p38α has allowed the molecular basis of this activation to be determined. GRA24 is shown to be intrinsically disordered, binding two kinases that act independently, and is the only factor required to bypass the canonical mitogen-activated protein kinase activation pathway. An adapted kinase interaction motif (KIM) forms a highly stable complex that competes with cytoplasmic regulatory partners. In addition, the recombinant complex forms a powerful in vitro tool to evaluate the specificity and effectiveness of p38α inhibitors that have advanced to clinical trials, as it provides a hitherto unavailable stable and highly active form of p38α.

---

Organizational Affiliation:

IAB, Team Host-Pathogen Interactions & Immunity to Infection, INSERM U1209, CNRS UMR5309, Université Grenoble Alpes, 38700 Grenoble, France. Electronic address: [e-mail].

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 14	A	360	Homo sapiens	Mutation(s): 0  Gene Names: MAPK14, CSBP, CSBP1, CSBP2, CSPB1, MXI2, SAPK2A EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for Q16539 (Homo sapiens) Explore Q16539  Go to UniProtKB:  Q16539
PHAROS:  Q16539

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Dual specificity mitogen-activated protein kinase kinase 6	B	15	Homo sapiens	Mutation(s): 0  Gene Names: MAP2K6, MEK6, MKK6, PRKMK6, SKK3 EC: 2.7.12.2
UniProt & NIH Common Fund Data Resources
Find proteins for P52564 (Homo sapiens) Explore P52564  Go to UniProtKB:  P52564
PHAROS:  P52564

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free: 0.231
• R-Value Work: 0.163
• R-Value Observed: 0.166
• Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 82.383	α = 90
b = 82.383	β = 90
c = 123.335	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Deposited Date: 2015-11-17
• Released Date: 2016-10-26
Deposition Author(s): Pellegrini, E., Palencia, A., Braun, L., Kapp, U., Bougdour, A., Belrhali, H., Bowler, M.W., Hakimi, M.

Revision History

• Version 1.0: 2016-10-26
  Type: Initial release

• Version 1.1: 2016-12-07
  Changes: Database references
• Version 1.2: 2017-01-18
  Changes: Database references
