5DL0

Crystal structure of glucosidase II alpha subunit (Glc1Man2-bound from)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.189
  • R-Value Work: 0.144
  • R-Value Observed: 0.146

wwPDB Validation   3D Report Full Report


This is version 2.0 of the entry. See complete history


Literature

Structural basis for two-step glucose trimming by glucosidase II involved in ER glycoprotein quality control.

Satoh, T.Toshimori, T.Yan, G.Yamaguchi, T.Kato, K.

(2016) Sci Rep 6: 20575-20575

  • DOI: https://doi.org/10.1038/srep20575
  • Primary Citation of Related Structures:
    5DKX, 5DKY, 5DKZ, 5DL0

  • PubMed Abstract:

    The endoplasmic reticulum (ER) has a sophisticated protein quality control system for the efficient folding of newly synthesized proteins. In this system, a variety of N-linked oligosaccharides displayed on proteins serve as signals recognized by series of intracellular lectins. Glucosidase II catalyzes two-step hydrolysis at α1,3-linked glucose-glucose and glucose-mannose residues of high-mannose-type glycans to generate a quality control protein tag that is transiently expressed on glycoproteins and recognized by ER chaperones. Here we determined the crystal structures of the catalytic α subunit of glucosidase II (GIIα) complexed with two different glucosyl ligands containing the scissile bonds of first- and second-step reactions. Our structural data revealed that the nonreducing terminal disaccharide moieties of the two kinds of substrates can be accommodated in a gourd-shaped bilocular pocket, thereby providing a structural basis for substrate-binding specificity in the two-step deglucosylation catalyzed by this enzyme.


  • Organizational Affiliation

    Graduate School of Pharmaceutical Sciences, Nagoya City University, 3-1 Tanabe-dori, Mizuho-ku, Nagoya 467-8603, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Alpha glucosidase-like protein951Thermochaetoides thermophila DSM 1495Mutation(s): 1
Gene Names: CTHT_0064960
UniProt
Find proteins for G0SG42 (Chaetomium thermophilum (strain DSM 1495 / CBS 144.50 / IMI 039719))
Explore G0SG42
Go to UniProtKB:  G0SG42
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG0SG42
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 2
MoleculeChains Length2D Diagram Glycosylation3D Interactions
alpha-D-glucopyranose-(1-3)-alpha-D-mannopyranose
B
2N/A
Glycosylation Resources
GlyTouCan:  G48717XG
GlyCosmos:  G48717XG
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.189
  • R-Value Work: 0.144
  • R-Value Observed: 0.146
  • Space Group: H 3 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 189.72α = 90
b = 189.72β = 90
c = 158.345γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
DENZOdata reduction
SCALEPACKdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
JSPS/MEXTJapan24770102, 25121730 to T.S. and 15H02491, 25102008, 24249002 to K.K.
PRESTO/JSTJapan13417569 to T.S.

Revision History  (Full details and data files)

  • Version 1.0: 2016-01-27
    Type: Initial release
  • Version 1.1: 2016-02-17
    Changes: Database references
  • Version 1.2: 2020-02-19
    Changes: Data collection, Derived calculations
  • Version 2.0: 2020-07-29
    Type: Remediation
    Reason: Carbohydrate remediation
    Changes: Atomic model, Data collection, Derived calculations, Structure summary
