5BNT

X-ray Crystal Structure of a Aspartate-semialdehyde dehydrogenase bound to NADP from Pseudomonas aeruginosa

• PDB DOI: https://doi.org/10.2210/pdb5BNT/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Pseudomonas aeruginosa PAO1
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2015-05-26 Released: 2015-06-10
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.220
• R-Value Work: 0.181
• R-Value Observed: 0.181

Starting Model: experimental

Literature

X-ray Crystal Structure of a Aspartate-semialdehyde dehydrogenase bound to NADP from Pseudomonas aeruginosa

Fairman, J.W., Abendroth, J., Lorimer, D.D., Edwards, T.E.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 169.25 kDa
• Atom Count: 12,304
• Modelled Residue Count: 1,481
• Deposited Residue Count: 1,512
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Aspartate-semialdehyde dehydrogenase	A [auth C], B, C [auth A], D	378	Pseudomonas aeruginosa PAO1	Mutation(s): 0  Gene Names: asd, PA3117 EC: 1.2.1.11
UniProt
Find proteins for Q51344 (Pseudomonas aeruginosa (strain ATCC 15692 / DSM 22644 / CIP 104116 / JCM 14847 / LMG 12228 / 1C / PRS 101 / PAO1)) Explore Q51344  Go to UniProtKB:  Q51344

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAP	E [auth C], F [auth B], G [auth A], H [auth D]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C21 H28 N7 O17 P3 XJLXINKUBYWONI-NNYOXOHSSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.220
• R-Value Work: 0.181
• R-Value Observed: 0.181
• Space Group: P 4₁ 2₁ 2
• Diffraction Data: https://doi.org/10.18430/M35BNT

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 125.68	α = 90
b = 125.68	β = 90
c = 199.44	γ = 90

Software Package:

Software Name	Purpose
XSCALE	data scaling
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
BALBES	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2015-06-10
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History

• Version 1.0: 2015-06-10
  Type: Initial release

• Version 1.1: 2017-09-27
  Changes: Author supporting evidence, Derived calculations, Source and taxonomy, Structure summary
• Version 1.2: 2019-12-11
  Changes: Author supporting evidence
• Version 1.3: 2023-09-27
  Changes: Data collection, Database references, Refinement description
