5A0M | pdb_00005a0m

THE CRYSTAL STRUCTURE OF I-SCEI IN COMPLEX WITH ITS TARGET DNA IN THE PRESENCE OF MN


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.249 (Depositor)
  • R-Value Work:
    0.186 (Depositor)
  • R-Value Observed:
    0.193 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5A0M

This is version 1.3 of the entry. See complete history

Literature

Structure of the I-Scei Nuclease Complexed with its DsDNA Target and Three Catalytic Metal Ions.

Prieto, J.Redondo, P.Merino, N.Villate, M.Montoya, G.Blanco, F.J.Molina, R.

(2016) Acta Crystallogr F Struct Biol Commun 72: 473

  • DOI: https://doi.org/10.1107/S2053230X16007512
  • Primary Citation Related Structures:
    5A0M

  • PubMed Abstract:

    Homing endonucleases are highly specific DNA-cleaving enzymes that recognize and cleave long stretches of DNA. The engineering of these enzymes provides instruments for genome modification in a wide range of fields, including gene targeting. The homing endonuclease I-SceI from the yeast Saccharomyces cerevisiae has been purified after overexpression in Escherichia coli and its crystal structure has been determined in complex with its target DNA. In order to evaluate the number of ions that are involved in the cleavage process, thus determining the catalytic mechanism, crystallization experiments were performed in the presence of Mn(2+), yielding crystals that were suitable for X-ray diffraction analysis. The crystals belonged to the orthorhombic space group P212121, with unit-cell parameters a = 80.11, b = 80.57, c = 130.87 Å, α = β = γ = 90°. The self-rotation function and the Matthews coefficient suggested the presence of two protein-DNA complexes in the asymmetric unit. The crystals diffracted to a resolution limit of 2.9 Å using synchrotron radiation. From the anomalous data, it was determined that three cations are involved in catalysis and it was confirmed that I-SceI follows a two-metal-ion DNA-strand cleavage mechanism.


  • Organizational Affiliation
    • Macromolecular Crystallography Group, Structural Biology and Biocomputing Programme, Spanish National Cancer Research Centre (CNIO), c/Melchor Fernandez Almagro 3, 28029 Madrid, Spain.

Macromolecule Content

  • Total Structure Weight: 86.38 kDa
  • Atom Count: 5,748
  • Modeled Residue Count: 548
  • Deposited Residue Count: 570
  • Unique protein chains: 2
  • Unique nucleic acid chains: 4

Macromolecules


Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
INTRON-ENCODED ENDONUCLEASE I-SCEI235Saccharomyces cerevisiaeMutation(s): 0
Gene Names: SCEIOMEGASECYQ0160
EC: 3.1
UniProt
Find proteins for P03882 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P03882
Go to UniProtKB:  P03882
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03882
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
INTRON-ENCODED ENDONUCLEASE I-SCEI235Saccharomyces cerevisiaeMutation(s): 0
Gene Names: SCEIOMEGASECYQ0160
EC: 3.1
UniProt
Find proteins for P03882 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P03882
Go to UniProtKB:  P03882
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP03882
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 3
MoleculeChains LengthOrganismImage
5'-D(*CP*AP*CP*GP*CP*TP*AP*GP*GP*GP*AP*TP*AP*AP)-3'
C, E
14synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 4
MoleculeChains LengthOrganismImage
5'-D(*GP*GP*TP*AP*TP*TP*AP*CP*CP*CP*TP*GP*TP*TP *AP*TP)-3'D,
F [auth H]
16synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 5
MoleculeChains LengthOrganismImage
5'-D(*CP*CP*CP*TP*AP*GP*CP*GP*TP)-3'G [auth I],
J [auth L]
9synthetic construct
Sequence Annotations
Expand
Reference Sequence
Find similar nucleic acids by:  Sequence
Entity ID: 6
MoleculeChains LengthOrganismImage
5'-D(*CP*AP*GP*GP*GP*TP*AP*AP*TP*AP*CP)-3'H [auth J],
I [auth K]
11synthetic construct
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.249 (Depositor)
  • R-Value Work:  0.186 (Depositor)
  • R-Value Observed: 0.193 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.113α = 90
b = 80.565β = 90
c = 130.871γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-05-04
    Type: Initial release
  • Version 1.1: 2016-06-08
    Changes: Database references
  • Version 1.2: 2016-06-29
    Changes: Database references
  • Version 1.3: 2024-01-10
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
