4YRZ | pdb_00004yrz

Crystal Structure of LuxP In Complex With L-xylulofuranose-1,2-borate

• PDB DOI: https://doi.org/10.2210/pdb4YRZ/pdb

• Classification: SIGNALING PROTEIN
• Organism(s): Vibrio harveyi
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2015-03-16 Released: 2016-03-23
• Deposition Author(s): McDonough, M.A., Sattin, S., Gardner, P.M., Liu, C., Davis, B.G.
• Funding Organization(s): Engineering and Physical Sciences Research Council, Royal Society

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.57 Å
• R-Value Free:
  0.224 (Depositor), 0.275 (DCC)
• R-Value Work:
  0.171 (Depositor)
• R-Value Observed:
  0.174 (Depositor)

Starting Model: experimental

Literature

Discovery of Glycomimetic Agonists from a Protocell Metabolism, Proto-natural Product Libraries

Sattin, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 79.07 kDa
• Atom Count: 5,643
• Modeled Residue Count: 679
• Deposited Residue Count: 690
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Autoinducer 2-binding periplasmic protein LuxP	A, B	345	Vibrio harveyi	Mutation(s): 0  Gene Names: luxP
UniProt
Find proteins for P54300 (Vibrio harveyi) Explore P54300  Go to UniProtKB:  P54300

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A2B	C [auth A], D [auth B]	L-xylulofuranose-1,2-borate C5 H10 B O7 HLBKGCVZIOGTKY-VPENINKCSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.57 Å
• R-Value Free:  0.224 (Depositor), 0.275 (DCC)
• R-Value Work:  0.171 (Depositor)
• R-Value Observed: 0.174 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 74.5	α = 90
b = 85.036	β = 90
c = 130.98	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
DENZO	data reduction
SCALEPACK	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2016-03-23
Deposition Author(s): McDonough, M.A., Sattin, S., Gardner, P.M., Liu, C., Davis, B.G.

---

Funding Organization	Location	Grant Number
Engineering and Physical Sciences Research Council	United Kingdom	EP/D023343/1, EP/D023327/1, EP/E000614/1
Royal Society	United Kingdom	--

Revision History

• Version 1.0: 2016-03-23
  Type: Initial release

• Version 2.0: 2017-09-13
  Changes: Advisory, Atomic model, Author supporting evidence, Derived calculations
• Version 2.1: 2024-01-10
  Changes: Data collection, Database references, Refinement description
