p107 pocket domain in complex with HPV E7 peptide

Experimental Data Snapshot

  • Resolution: 2.25 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.184
  • R-Value Observed: 0.189

wwPDB Validation   3D Report Full Report

This is version 1.5 of the entry. See complete history


Structural mechanisms of DREAM complex assembly and regulation.

Guiley, K.Z.Liban, T.J.Felthousen, J.G.Ramanan, P.Litovchick, L.Rubin, S.M.

(2015) Genes Dev 29: 961-974

  • DOI: https://doi.org/10.1101/gad.257568.114
  • Primary Citation of Related Structures:
    4YOO, 4YOS, 4YOZ

  • PubMed Abstract:

    The DREAM complex represses cell cycle genes during quiescence through scaffolding MuvB proteins with E2F4/5 and the Rb tumor suppressor paralog p107 or p130. Upon cell cycle entry, MuvB dissociates from p107/p130 and recruits B-Myb and FoxM1 for up-regulating mitotic gene expression. To understand the biochemical mechanisms underpinning DREAM function and regulation, we investigated the structural basis for DREAM assembly. We identified a sequence in the MuvB component LIN52 that binds directly to the pocket domains of p107 and p130 when phosphorylated on the DYRK1A kinase site S28. A crystal structure of the LIN52-p107 complex reveals that LIN52 uses a suboptimal LxSxExL sequence together with the phosphate at nearby S28 to bind the LxCxE cleft of the pocket domain with high affinity. The structure explains the specificity for p107/p130 over Rb in the DREAM complex and how the complex is disrupted by viral oncoproteins. Based on insights from the structure, we addressed how DREAM is disassembled upon cell cycle entry. We found that p130 and B-Myb can both bind the core MuvB complex simultaneously but that cyclin-dependent kinase phosphorylation of p130 weakens its association. Together, our data inform a novel target interface for studying MuvB and p130 function and the design of inhibitors that prevent tumor escape in quiescence.

  • Organizational Affiliation

    Department of Chemistry and Biochemistry, University of California at Santa Cruz, Santa Cruz, California 95064, USA;

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Retinoblastoma-like protein 1,Retinoblastoma-like protein 1371Homo sapiensMutation(s): 0
Gene Names: RBL1
UniProt & NIH Common Fund Data Resources
Find proteins for P28749 (Homo sapiens)
Explore P28749
Go to UniProtKB:  P28749
PHAROS:  P28749
GTEx:  ENSG00000080839
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP28749
Sequence Annotations
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
HPV E7 peptide9Human papillomavirusMutation(s): 0
Find proteins for P03129 (Human papillomavirus type 16)
Explore P03129
Go to UniProtKB:  P03129
Entity Groups
UniProt GroupP03129
Sequence Annotations
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Resolution: 2.25 Å
  • R-Value Free: 0.240
  • R-Value Work: 0.184
  • R-Value Observed: 0.189
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.69α = 90
b = 76.55β = 120.32
c = 74.68γ = 90
Software Package:
Software NamePurpose
Cootmodel building
Blu-Icedata collection
iMOSFLMdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesR01CA132685

Revision History  (Full details and data files)

  • Version 1.0: 2015-06-24
    Type: Initial release
  • Version 1.1: 2015-09-09
    Changes: Other
  • Version 1.2: 2017-09-20
    Changes: Author supporting evidence, Derived calculations, Refinement description
  • Version 1.3: 2017-09-27
    Changes: Data collection
  • Version 1.4: 2019-12-04
    Changes: Author supporting evidence
  • Version 1.5: 2024-02-28
    Changes: Data collection, Database references
