4YJW | pdb_00004yjw

Crystal structure of a DUF3829 family protein (BVU_3067) from Bacteroides vulgatus ATCC 8482 at 1.80 A resolution

PDB DOI: https://doi.org/10.2210/pdb4YJW/pdb

Classification: STRUCTURAL GENOMICS UNKNOWN FUNCTION
Organism(s): Phocaeicola vulgatus ATCC 8482
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2015-03-03 Released: 2015-03-18
Deposition Author(s): Joint Center for Structural Genomics (JCSG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free:
0.195 (Depositor), 0.193 (DCC)
R-Value Work:
0.173 (Depositor), 0.173 (DCC)
R-Value Observed:
0.174 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 4YJW

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of a DUF3829 family protein (BVU_3067) from Bacteroides vulgatus ATCC 8482 at 1.80 A resolution

Joint Center for Structural Genomics (JCSG)

To be published.

Macromolecule Content

Total Structure Weight: 19.56 kDa
Atom Count: 1,478
Modeled Residue Count: 153
Deposited Residue Count: 169
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DUF3829 family protein	A	169	Phocaeicola vulgatus ATCC 8482	Mutation(s): 0 Gene Names: BVU_3067
UniProt
Find proteins for A6L4U0 (Phocaeicola vulgatus (strain ATCC 8482 / DSM 1447 / JCM 5826 / CCUG 4940 / NBRC 14291 / NCTC 11154)) Explore A6L4U0 Go to UniProtKB: A6L4U0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A6L4U0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.80 Å
R-Value Free: 0.195 (Depositor), 0.193 (DCC)
R-Value Work: 0.173 (Depositor), 0.173 (DCC)
R-Value Observed: 0.174 (Depositor)

Diffraction Data:

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.766	α = 90
b = 70.766	β = 90
c = 67.473	γ = 90

Software Package:

Software Name	Purpose
PDB_EXTRACT	data extraction
SHELX	phasing
SHARP	phasing
XDS	data scaling
BUSTER-TNT	refinement
XSCALE	data scaling
SHELXD	phasing
BUSTER	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2015-03-18

Deposition Author(s):

Joint Center for Structural Genomics (JCSG)

Revision History (Full details and data files)

Version 1.0: 2015-03-18
Type: Initial release
Version 1.1: 2017-11-22
Changes: Derived calculations, Refinement description, Source and taxonomy
Version 1.2: 2018-01-24
Changes: Database references
Version 1.3: 2024-11-13
Changes: Data collection, Database references, Structure summary
